With the arrival of the new 400 cc engine, the Atlantic Sprint range offers more choice than ever, with not just one scooter but an entire family to…
| MODEL | ATLANTIC 400 SPRINT |
| ENGINE TYPE | Liquid cooled single cylinder four-stroke. SOHC (Single OverHead Cam), four valves |
| Year | 2007 - 2009 |
| Displacement / Capacity | 460 L |
| Bore X Stroke | 92 x 69 mm (86 x 69 mm). |
| Compression | 10.5:1. |
| Cooling System | — |
| Max Power | 27.5 kW – 37.4 HP at 7,250 rpm (25 kW – 34 HP at 7,500 rpm) |
| Max Torque | 42 Nm at 5,500 rpm (37 Nm at 5,500 rpm) |
| Ignition | Electronic CDI with automatic advance. |
| Induction | — |
| ---------------------- | |
| TRANSMISSION SPECS | |
| Lubrification | Wet sump. Forced lubrication with mechanical oil pump. |
| Gear Box | Automatic variator. |
| Clutch | Automatic centrifugal dry clutch. |
| Primary Drive | V belt. |
| Final Drive | Gearbox |
| ---------------------- | |
| CHASSIS SPECS | |
| Frame | High-strength tubular steel frame with closed double cradle. |
| Front Suspension | 35 mm hydraulic fork. Wheel travel 105 mm. |
| Rear Suspension | Engine acting as swingarm. Two gas filled shock absorbers with 5 position spring preload adjustment. / Wheel travel 90 mm. |
| Front Brakes | 260 mm (diam.) stainless steel disc with floating three piston caliper and integral braking system |
| Rear Brakes | 190 mm (diam.)stainless steel disc with integral braking system. |
| ---------------------- | |
| DIMENSION SPECS | |
| Overall Length | 2,200 mm |
| Seat Height | 780 mm |
| Overall height | 1,370 mm (at windshield) |
| Width | 815 mm (at handlebars) |
| ---------------------- | |
| WHEEL SPECS | |
| Front Tyre | 120/70 x 14". |
| Rear Tyre | 140/60 x 14". |
| Front Wheel / Rim | Light alloy. 3.00 x 14" |
| Rear Wheel / Rim | Light alloy. 3.75 x 14". |
| ---------------------- | |
| FUEL SYSTEM | |
| Fuel System | Electronic fuel injection. |
| Fuel Capacity | 15 litres (2 litre reserve). |
| Fuel | Unleaded petrol. |
| Fuel Consumption | — |
| Starting | Electric. |
| Alternator | 12 V – 380 W |
With the arrival of the new 400 cc engine, the Atlantic Sprint range offers more choice than ever, with not just one scooter but an entire family to choose from, all built to fulfil your every need, and all offering the legendary style and superb ride that have become trademarks of Aprilia motorcycles and scooters. The Atlantic Sprint opens up new horizons in personal mobility, thanks to advanced, clean running high performance engines (both Euro 3 homologated), standard-setting comfort and unmistakeable style. Its agility and sparkling performance make the Atlantic Sprint unbeatable around town. Plenty of room, comfort, excellent wind protection, and large capacity (400 and 500 cc), high-performance engines mean that the Atlantic Sprint is great on country roads, and a classy performer on long distance touring holidays. The Atlantic Sprint’s styling is a passport to success, clear-cut no-frills lines, elegant colours, and a dynamic but elegant look that hides advanced scooter technology. The Atlantic Sprint is Aprilia’s answer to scooter riders who have been waiting for a fast and safe machine that promises high performance urban commuting without compromising on comfort.
