| MODEL | APRILIA RSV 4 RR |
| ENGINE TYPE | Four Stroke, longitudinal 65° V four , DOHC, 4 valves per cylinder |
| Year | 2019 |
| Displacement / Capacity | 999.6 cc / 61.0 cu-in |
| Bore X Stroke | 78 x 52.3 mm |
| Compression Ratio | 13.6:1 |
| Cooling System | Liquid Cooled |
| Max Power | 148 kW / 201 hp @ 13000 rpm |
| Max Torque | 115 Nm / 11.9 kgf-m / 86.2 lb-ft @ 10500 rpm |
| Ignition | Magneti Marelli digital electronic ignition system integrated in engine control system, with one spark plug per cylinder and “stick-coil”-type coils |
| Induction | Choice of three different engine maps selectable by the rider with bike in motion: T (Track), S (Sport), R (Race). / Airbox with front dynamic air intakes. 4 Marelli 48-mm throttle bodies with 8 injectors and latest generation Ride-By-Wire engine management. |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling) |
| Gear Box | 6 Speed gearbox, cassette type |
| Clutch | Multi-disc oil bath with mechanical slipper system |
| Primary / Final Drive | Chain, Straight cut gears and integrated flexible coupling, drive ratio: 73:44 |
| Secondary drive | Secondary drive Chain: Drive ratio: 42:16 (2.625) |
| Gear Ratio | 1st: 39/15 (2.600) 2nd: 33/16 (2.063) 3rd: 34/20 (1.700) 4th: 31/21 (1.476) 5th: 31/23 (1.348) 6th: 34/27 (1.259) |
| CHASSIS SPECS | |
| Frame | Dual aluminium beam chassis with pressed and cast sheet elements |
| Front Suspension | Sachs upside-down fork, 43-mm stanchions (with Tin surface treatment). Low profile forged aluminium radial caliper mounting bracket. / Adjustable spring preload, hydraulic compression and rebound damping |
| Rear Suspension | Twin sided aluminium swingarm mixed low thickness and sheet casting technology. / Sachs monoshock, adjustable, spring preload, wheelbase and hydraulic compression and rebound damping. APS progressive / linkages. |
| Front Brakes | 2 x Ø320 mm diameter floating stainless steel disc with lightweight stainless steel rotor and aluminium flange with 6 pins. / Brembo monobloc radial calipers with 4 x Ø30 mm opposing. Sintered pads. Radial pump and metal braided brake hose |
| Rear Brakes | Single Ø220 mm diameter disc, Brembo floating caliper with two Ø32 mm isolated pistons. Pump with integrated tank and metal / braided hose |
| Exhaust System | 4 into 2 into 1 layout, two oxygen sensors, lateral single silencer with ECU-controlled bypass valve and integrated trivalent catalytic converter / (Euro 4) |
| DIMENSION SPECS | |
| Overall Length | 2040 mm / 80.3 in |
| Seat Height | 845 mm / 33.2 in |
| Overall height | 1120 mm / 44.0 in |
| Width | 735 mm / 28.9 in (at the handlebar) |
| Overall Weight | Dry Weight - 182 kg / 401 lbs / Wet Weight - 204 kg / 450 lbs |
| WHEEL SPECS | |
| Front Tyre | Radial tubeless. 120/70 ZR 17 |
| Rear Tyre | Radial tubeless. 200/55 ZR 17 (alternative: 190/50 ZR 17; 190/55 ZR 17) |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Wheel Travel | 130 mm / 5.1 in |
| Trail | 105 mm / 4.1 in |
| FUEL SYSTEM | |
| Fuel System | Airbox with front dynamic air intakes. Variable length intake ducts controlled via the engine control unit. 4 Marelli 48-mm throttle bodies with / 8 injectors and latest generation Ride-By-Wire engine management. / Multiple engine maps selectable by the rider with bike in motion: T (Track), S (Sport), R (Race) |
| Fuel Capacity | 18.5 Litres / 4.9 US gal |
| Fuel Reserve | 4 Liters / 1.1 US gal |
| _________ | — |
| Standing ¼ mile | — |
| Top Speed | Top Speed: 180 mph (Est.) |
| CAPACITIES | |
| Fork oil per rod | — |
| Engine oil w/o Filter | — |
| Engine oil with filter | — |
| Brake fluid | DOT 4 |
| Coolant | WATER + |
When a manufacturer pours its blood, sweat, and tears into racing on the world stage, the result is something that moves the masses. In our case, the result comes with ruthless power output, knife-edge handling, and serious electronic capabilities. Its name? The Aprilia RSV4 RR. The RR model arrives in 2019 as a proven race winner with updates to make it just that much better. The Focus on 2019 Should the bystanders somehow miss the unmistakable soundtrack produced by the RSV4’s engine, they’re sure to catch its new, distinctive appearance. The 2019 model year sees a redesigned graphics package, aimed at the dark side. Its new color way focuses on keeping the RSV4’s subtle, but with bright red accents and aluminum alloy wheels. Go ahead; try to get your eyes off of it. Powered by Legendary V4 Power The heart of the RSV4 remains the same for the new model year, and for good reason. Its 999cc V4 engine is widely accepted as the most powerful, yet tractable powerplant in the modern superbike class. How does 201 horsepower at a screamin’ 13,000 rpm sound? We like to call it a seriously throaty pitch—one so distinct that it will turn heads at the coffee shop and racing paddock alike. We put our best engineers to work on the RSV4, which means the V4 was given special treatment, like extremely lightweight pistons, a unique honing treatment for the connecting rods, and gearbox that offers crisp shifting every time. There were no details missed on the V4, not one. Oh, and to keep the power in control, we’ve given it the most advanced electronic package on the market—the Aprilia Ride Performance Control. Multi-level Aprilia Traction Control (ATC) and Aprilia Wheelie Control (AWC) systems keep things racing forward, while the Aprilia Quickshift (AQS) and Aprilia Launch Control (ALC) save every tenth possible. Superbike Handling for the Everyday Rider Spend one hour aboard an RSV4 RR carving corners on canyon twisties or destroying apexes at the local track day. In that one hour, the V4 superbike’s chassis will bring you as close to a real-life superhero as possible, period. The RSV4 gets all the best chassis components, and nothing less. Its main frame is the same that’s used in cutthroat WSBK competition, and complemented by a set of 43mm Sachs front forks and a Sachs monoshock out back. Feel? This RSV4 RR has got all of it. The only thing that can possibly compare is our RSV4 RF, which arrives stock with Öhlins Suspension. Adjustability for individual riders is key. That’s why we’ve given the RSV4 engine position, swingarm pivot, and headstock adjustability. All straightaways come to an end. So, what better than a set of top-shelf Brembo M50 monobloc front brake calipers to bring the RSV4 to a halt? Yeah, we thought you’d like that. Source: Aprilia.com
Video Courtessy of PowerDrift
