The 2017 RF received the same Euro 4 engine update, M50 brakes, cornering ABS, up-and-down quickshifter and TFT dash as the RR, but stays the…
| MODEL | APRILIA RSV4 RF 2017 |
| Year | 2017 |
| Engine Type | Four stroke, longitudinal 65° V4, DOHC, 4 valves per cylinder |
| Displacement / Capacity | 999.6 cc / 61.0 cu in |
| Bore X Stroke | 78 x 52.3 mm / 3.07 x 2.06 in |
| Compression Ratio | 13.6:1 |
| Cooling System | Liquid cooled |
| Max Power | 148 kW / 201 hp @ 13000 rpm |
| Max Torque | 115 Nm / 84.8 lb-ft @ 10500 rpm |
| Ignition | Marelli digital electronic ignition, one spark plug per cylinder, stick coils |
| Induction | 4 Marelli 48 mm throttle bodies, 8 injectors, Ride-by-Wire; 3 engine maps (T, S, R) |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Wet sump, two pumps (lubrication and cooling), oil cooler |
| Gear Box | 6-speed cassette type, Aprilia Quick Shift (up and down) |
| Clutch | Wet multi-plate with mechanical slipper system |
| Final Drive | Chain |
| CHASSIS SPECS | |
| Frame | Dual aluminium beam chassis with pressed and cast sheet elements |
| Front Suspension | Öhlins NIX 43 mm fork with TiN treatment, adjustable preload, compression and rebound damping, 120 mm / 4.7 in travel; adjustable Öhlins steering damper |
| Rear Suspension | Double-braced aluminium swingarm, Öhlins TTX piggy-back monoshock, fully adjustable (preload, length, compression, rebound), APS progressive linkage, 130 mm / 5.1 in travel |
| Front Brakes | 2 x 330 mm / 13 in floating discs, Brembo M50 monobloc radial 4-piston calipers, Bosch 9.1 MP cornering ABS |
| Rear Brakes | Single 220 mm disc, Brembo floating caliper, 2 x 32 mm pistons |
| DIMENSION SPECS | |
| Overall Length | 2055 mm / 80.5 in |
| Overall Width | 735 mm / 29 in |
| Overall Height | 1120 mm / 44 in |
| Seat Height | 845 mm / 33.2 in |
| Wheelbase | 1435 mm / 56.5 in |
| Ground Clearance | 130 mm / 5.1 in |
| Dry Weight | 180 kg / 397 lbs |
| Wet Weight | 204 kg / 450 lbs |
| WHEEL SPECS | |
| Front Tyre | 120/70 ZR17 |
| Rear Tyre | 200/55 ZR17 (alt. 190/50 ZR17, 190/55 ZR17) |
| FUEL SYSTEM | |
| Fuel Capacity | 18.5 Litres / 4.9 US gal (incl. 4 L reserve) |
| Fuel Consumption | — |
| Top Speed | — |
The 2017 RF received the same Euro 4 engine update, M50 brakes, cornering ABS, up-and-down quickshifter and TFT dash as the RR, but stays the top-shelf version. It moves to the newer Öhlins NIX fork and TTX shock with an adjustable Öhlins steering damper, rolls on machined forged five-spoke wheels, and gets the V4-MP telemetry platform as standard. Superpole-style graphics complete the package.
