Unanimously acclaimed by critics and sought after by bikers from every corner of the globe, the RSV4 has always been the undisputed segment…
| MODEL | Aprilia RSV-4 RR Misano Limited Edition |
| ENGINE TYPE | Four stroke, longitudinal 65° V four , DOHC, 4 valves per cylinder |
| Year | 2020 |
| Displacement / Capacity | 999.6 cc / 61.0 cu-in |
| Bore X Stroke | 78 x 52.3 mm |
| Compression Ratio | 13.6:1 |
| Cooling System | Liquid Cooled |
| Max Power | 148 kW / 201 hp @ 13000 rpm |
| Max Torque | 115 Nm / 11.9 kgf-m / 86.2 lb-ft @ 10500 rpm |
| Ignition | Magneti Marelli digital electronic ignition system integrated in engine control system, with one spark plug per cylinder and / “stick-coil”-type coils |
| Induction | Airbox with front dynamic air intakes. 4 Marelli 48-mm throttle bodies with 8 injectors and latest generation Ride-By-Wire engine management. / Choice of three different engine maps selectable by the rider with bike in motion, Track, Sport, Race |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling) |
| Gear Box | 6 Speed gearbox - Cassette type |
| Clutch | Multi-disc oil bath with mechanical slipper system |
| Primary / Final Drive | Final Drive : Chain / Primary Drive : Straight cut gears and integrated flexible coupling, drive ratio: 73:44 (1,659) |
| Secondary drive | Secondary drive Chain: Drive ratio: 42:16 (2.625) |
| Gear Ratio | 1st: 39/15 (2.600) 2nd: 33/16 (2.063) 3rd: 34/20 (1.700) 4th: 31/21 (1.476) 5th: 31/23 (1.348) 6th:; 34/27 (1.259) |
| CHASSIS SPECS | |
| Frame | Aluminium dual beam chassis with pressed and cast sheet elements Available adjustments: headstock position and rake, / engine height, swingarm pin height. Smart EC 2.0 electronically managed Öhlins steering damper [Sachs steering damper] |
| Front Suspension | Smart EC 2.0 electronically managed Öhlins NIX fork. 43 mm stanchions, with TIN surface treatment. [Sachs fork with 43 mm stanchions], / Aluminium radial calliper mounting bracket. Adjustable spring pre-load and hydraulic compression and rebound damping. |
| Rear Suspension | Sachs monoshock adjustable in: hydraulic compression and rebound damping, spring pre-load and centre-to-centre distance. |
| Brakes | Front Brakes: / 2 x 330-mm diameter floating stainless steel disc with lightweight stainless steel rotor and / aluminium flange with 6 pins. Brembo Stylema® [M50] monobloc radial callipers with 4 30 mm opposing pistons. Sintered pads. / Radial pump and metal braided brake hose. / / Rear Brakes : / Single 220 mm diameter disc; Brembo calliper with two 32 mm separate pistons. Sintered pads. / Pump with integrated tank and metal braided hose Bosch 9.1 MP ABS with cornering function, adjustable to 3 maps equipped with / RLM (Rear wheel Lift-up Mitigation) (can be disabled). |
| Traction Management | APRC System (Aprilia Performance Ride Control), which includes Traction Control (ATC), Wheelie Control (AWC), Launch Control (ALC), / cruise control (ACC) and speed limiter (APT), all of which can be configured and deactivated independently |
| Exhaust System | 4 into 2 into 1 layout, two lambda probes, lateral single silencer with ECU-controlled bypass valve and integrated trivalent / catalytic converter |
| DIMENSION SPECS | |
| Overall Length | 2055 mm / 80.9 in |
| Seat Height | 853 mm / 33.5 in |
| Ground Clearance | 130 mm / 5.1 in |
| Width | 735 mm / 28.9 in (at the handlebar) |
| Overall Weight | Dry Weight - 182 kg / 401 lbs / Wet Weight - 204 kg / 450 lbs |
| Wheelbase | 1441.6 mm / 56.7 in |
| WHEEL SPECS | |
| Wheels / Rims | Aprilia in aluminium alloy wheels with 3 split spoke design / Front Wheel : / 3.5 x 17 / / Rear Wheel: / 6.0 x 17 |
| Front Tyre | Radial tubeless 120/70 ZR17 |
| Rear Tyre | Radial tubeless 200/55 ZR 17 (alternative: 190/50 ZR 17; 190/55 ZR 17) |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Wheel Travel | 130 mm / 5.1 in |
| Trail | 103 mm / 4.0 in |
| Steering Angle | 24.5° |
| FUEL SYSTEM | |
| Fuel Capacity | 18.5 Litres / 4.9 US gal |
| Fuel Reserve | 4 Liters / 1.1 US gal |
| CAPACITIES | |
| Fork oil per rod | — |
| Engine oil w/o Filter | — |
| Engine oil with filter | — |
| Brake fluid | — |
| Top Speed | 177.7 mph (286.0 km/h) |
Unanimously acclaimed by critics and sought after by bikers from every corner of the globe, the RSV4 has always been the undisputed segment representative, the reference point for sportiness and performance, the best example of what can be achieved by exploiting the valuable experience of a victorious Racing Department like Aprilia's which, in its brief history has taken 54 championship titles. Skills honed on the track and transferred to the factory product to provide everyone with the same excitement that the motorbikes prepared by Aprilia Racing do. The primary goal followed during development of the new Aprilia RSV4 (in both available versions, RSV4 RR and RSV4 RF) is, as always, only one: to be the fastest superbike in the segment. In order to achieve it, Aprilia drew from the best Aprilia Racing technology, refining the already exceptional RSV4 in many aspects, such as electronics, suspension and brakes. Thanks in part to the work done on the powerplant, now compliant with the Euro 4 regulation, without sacrificing anything in terms of power and range of use, the new RSV4 is one second faster than the previous version on average. The primary and unique characteristics of this gem of Italian technology, the ones that led to the creation of the best superbike of all times, remain unchanged. This is the world's first full scale production motorcycle with a high performance narrow V4 engine, the most revolutionary and powerful engine ever built by Aprilia. An engine that has been made unmistakable because of the use of "total" electronics, because of its extremely compact size and light weight. The changes implemented in this evolution of the Italian V4 not only resulted in achieving the goals of Euro 4 approval, but also increasing overall reliability and performance, without sacrificing power and maximum torque (which remain respectively at 201 HP at 13,000 rpm and 115 Nm at 10,500 rpm), and not even that inimitable sound that has always been a true soundtrack of the Aprilia V4 engines. The powerplant earns a new exhaust system with a silencer that has a double oxygen sensor and a built-in valve. The engine ECU is new, with superior calculating capacity able to manage the rise in maximum revs, now 300 rpm higher. Therefore, the engine now boasts an increased extension capacity and it was also for this reason that the variable timing intake ducts were eliminated, no longer deemed necessary. This decision contributed to reducing the weight of the fuel system parts by 500 grams. In order to increase performance and reliability, new and lighter pistons were introduced with brand new segments that reduce the blow-by effect. Furthermore, a honing treatment was added for the connecting rod heads, further reducing friction. The valve recall springs are also new in order to guarantee reliability during the heaviest operating loads, whereas the valves have benefited from optimized timing, capable of increasing performance and reliability. Last, but not least, the gearbox now has a linear sensor that guarantees impeccable gearshift operation.
