| MODEL | CHOPPER 125 |
| ENGINE TYPE | Single cylinder, two-stroke |
| Year | 1995 - 96 |
| Displacement / Capacity | 124.8 cc / 7.5 cu in |
| Bore X Stroke | 54 x 54.5 mm |
| Compression | 12.5:1 |
| Cooling System | Liquid cooled |
| Max Power | 11.2 kW / 15 hp @ 6600 rpm |
| Max Torque | 12.7 Nm / 1.3 kgf-m 9.4 lb-ft @ 6500 rpm |
| Ignition | CDI |
| Induction | Dell'Orto PHBH 28 RD carburetor |
| ---------------------- | |
| TRANSMISSION SPECS | |
| Lubrification | — |
| Gear Box | 6 Speed |
| Clutch | — |
| Primary Drive | Chain |
| Final Drive | — |
| ---------------------- | |
| CHASSIS SPECS | |
| Frame | Double open cradle |
| Front Suspension | Telescopic fork |
| Rear Suspension | 2 x Hydraulic shock absorbers |
| Front Brakes | Single Ø230 mm disc, 2 piston caliper |
| Rear Brakes | Drum, Ø160 mm |
| ---------------------- | |
| DIMENSION SPECS | |
| Overall Length | 2300 mm / 90.6 in |
| Seat Height | — |
| Overall height | 1120 mm / 44.1 in |
| Width | 780 mm / 30.7 in |
| ---------------------- | |
| WHEEL SPECS | |
| Front Tyre | 90/90-19 |
| Rear Tyre | 130/90-16 |
| Front Wheel / Rim | 1.85 x 19 |
| Rear Wheel / Rim | 2.50 x 16 |
| ---------------------- | |
| FUEL SYSTEM | |
| Fuel System | — |
| Fuel Capacity | 10 Liters / 2.6 US gal |
| Fuel Reserve | 2 Liters / 0.5 US gal |
| Fuel Consumption | 2.8 L/100 km / 35.2 km/l / 83 US mpg |
| Starting | Electric |
| Alternator | — |
Spec sheet below — full write-up coming soon.
