BMW F 800R - 2017

2017 BMW F 800R FACTORY SPECIFICATIONS
2017 BMW F 800R FACTORY SPECIFICATIONS
Spec sheet
MODELBMW F 800R
ENGINE TYPEFour stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Year2017
Displacement / Capacity798 cc / 47.7 cub. in.
Bore X Stroke82 x 75.8 mm
Compression Ratio12.0:1
Cooling SystemLiquid cooled
Max Power66 kW / 90 hp @ 8000 rpm
Max Torque86 Nm / 8.8 kgf-m / 63 lbs/ft @ 8000 rpm
IgnitionControl and oxygen sensors.
InductionElectronic injection, digital engine electronics (BMS-KP)
Start SystemElectric
TRANSMISSION SPECS
LubricationWet sump
Gear BoxConstant-mesh 6-speed gearbox with straight cut gears
ClutchMulti-plate clutch in oil bath, mechanically operated
Primary / Final DriveFinal Drive : / Primary Drive :
Drive Chain drive2.35:1
Gear Ratio1st I2.462 / 2nd 1.750 / 3rd 1.381 / 4th 1.227 / 5th 1.130 / 6th 1.042:1
CHASSIS SPECS
FrameBridge frame made aluminium, load-supporting the engine
Front Suspension43mm Telescopic fork
Rear SuspensionCast aluminium double-sided swing arm, central, suspension strut, spring pre-tension by means of hand
BrakesFront Brakes: Dual floating disc brakes, 4-piston fixed calipers, diameter 320 mm / Rear Brakes : Single disc brake, diameter 265 mm, single-piston floating caliper /
Traction Management—
Exhaust System—
DIMENSION SPECS
Overall Length84.5″ (2,145 mm)
Seat Heightunladen weight 31.1″ (790 mm) Standard; variable seat heights available between 30.3″ (770 mm) and 33.1″ (840 mm) / (available as accessories and/or factory options, see an authorized BMW Motorrad dealer)
Ground Clearance—
Overall Width(incl. mirrors) 33.9″ (860 mm)
Overall WeightDry Weight - 77 kg / 390 lbs / Wet Weight - 199 kg / 439 lbs.
Wheelbase60.1″ (1,526 mm)
Rake and TrailRake: / Trail:
WHEEL SPECSCast aluminum wheels
Wheels / RimsFront Rims : 3.50 x 17″ / Rear rims : 5.50 x 17″ /
Front Tyre120/70 ZR 17
Rear Tyre180/55 ZR 17
Front Wheel Travel125 mm / 4.9 in.
Rear Wheel Travel125 mm / 4.9 in.
Castor3.9″ (100 mm)
Steering Angle64°
FUEL SYSTEM
Fuel Capacity16 Litres / 4.2 US gal
Fuel Reserve3.0 Litres / 0.8 gal
Fuel Consumption—
CAPACITIES
Engine oilSAE 15W-50
Brake fluidDOT 4
Top Speed—
Photo gallery
2017 BMW F 800R SPECS 2017 BMW F 800R BMW 2017 F800R photo 2017 BMW F800R SPECS 2017 BMW F 800R FACTORY SPECIFICATIONS BMW F 800R - 2017 2017 BMW F 800R FACTORY SPECIFICATIONS
BMW file

You can do anything with this active roadster, from urban cruising, touring or ambitious sporty riding on winding country roads. The BMW F 800 R combines agility, everyday practicality and dynamic performance in an integrated sporty package. Thanks to its punchy 66 kW (90 hp) engine, you’ll feel what it’s made for every time you twist the throttle: supreme handling and total control of the road. But the F 800 R delivers more than just sporty performance and easy handling, it also features innovative technology, Ride-by-Wire and a range of riding modes, ABS as standard and optional systems like ASC or Dynamic ESA make sure all that power is transferred securely to the road. Design you can enjoy. You can tell by its looks alone,The F 800 R is the perfect bike if you want to get on and have fun. The precise lines and minimalist trim elements give it a sense of light-footed agility, while the upside-down fork is suggestive of dynamic forward thrust even when stationary. The high-performance cockpit features a new dial design and the clear multifunction display now gives you even more information. Another highlight is the new rear silencer, which not only looks as good as it sounds, it also meets the EU-4 standard. Three new colours accentuate the bike’s dynamic design. The F 800 R looks especially sporty and dynamic in BMW motorsport colours. It comes with a red wheel lining in tribute to the S 1000 RR – the iconic superbike Powerful two-cylinder for dynamic thrust. A powerful, water-cooled 798 cc two-cylinder in-line engine ensures dynamic forward propulsion. With 66 kW (90 hp) of power at 8000 rpm, it features fast response characteristics, impressive punch and excellent fuel efficiency. A reduced-power version with 35 kW (48 hp) is also available for new riders under the age of 25. Move ahead safely. The F 800 R is designed for pure and simple riding pleasure, but safety is also a priority: All models feature a BMW Motorrad ABS and a stable, balanced suspension for supreme performance and absolute control of the road. Other options include ASC (Automatic Stability Control) and Dynamic ESA (Electronic Suspension Adjustment) for even greater safety, performance and comfort. Ride-by-Wire gives you much finer throttle control. Thanks to the standard Rain and Road modes and the optional Dynamic mode, the F 800 R can be adapted even better to any road surface and riding style. Limitless personalisation. You can tailor the bike to meet your exact ergonomic needs thanks to standard adjustable clutch and brake levers and a large selection of seat variations. BMW Motorrad also offers a wide range of optional equipment and accessories for personalising your F 800 R. For example, you can choose the new raised handlebars. Combined with a low seat, this option is perfect for a more relaxed riding position, especially for smaller riders. Colours F 800 R: Racing Red non-metallic, Blackstorm metallic, BMW Motorsport (Lightwhite non-metallic/Lupine Blue metallic/Racing Red non-metallic).
