| ENGINE | |
| Type | Air/oil-cooled 4-stroke flat twin engine with balancer shaft, four valves per cylinder, double overhead camshaft, wet sump lubrication |
| Bore x stroke | 101 mm x 73 mm |
| Capacity | 1,170 cc |
| Max. torque | 86 lb-ft (116 Nm) at 6,000 rpm |
| Compression ratio | 12.0:1 |
| Mixture control / engine management | Electronic intake pipe injection |
| Emission control | Closed-loop 3-way catalytic converter, emission standards EU-4 |
| Maximum speed | Over 125 mph / 201 kph |
| Battery | 12 V / 14 Ah, maintenance free |
| Clutch | Single dry plate clutch, hydraulically operated |
| Gearbox | Claw-shifted 6-speed transmission with helical-cut splines |
| Front wheel location / suspension | Telescopic forks with 43 mm fixed-tube diameter |
| Rear wheel location / suspension | Cast aluminum single swing arm with BMW Motorrad Paralever; central spring strut, spring preload fully adjustable by hook wrench, adjustable rebound-stage damping |
| Front Rim | 3.00 x 19″ |
| Rear Rim | 4.50 x 17″ |
| Front Tyre | 120/70 R 19 |
| Rear Tyre | 170/60 R 17 |
| Front Brake | Twin-disc brakes, diameter 320 mm, 4-piston calipers |
| Rear Brake | Single disc brake, diameter 265 mm, double-piston floating caliper |
| ABS | BMW Motorrad ABS |
| Length | 2,175 mm |
| Height | 1,330 mm |
| Fuel type | Premium Unleaded |
| Fuel Capacity | 17 Litres |
| Fuel Reserve | 3.5 Litres |
Enjoy the confident feel of a boxer with an upright and relaxed riding position, coupled with modern technology. Choose from countless customizing options for your own unique ideas. The R nineT Urban G/S makes a clear statement: It pays tribute to the early days of BMW Motorrad’s G/S success story. Just one look and it’s clear that the R nineT Urban G/S captures the off-road spirit of that era. At the same time, its riding characteristics make it a true member of today’s R nineT family. It reflects the way of life of that time: People knew where they wanted to go, and they knew exactly how they would get there. The source of inspiration: unmistakable. The design of the R nineT Urban G/S is eye-catching. Distinctive stylistic elements make it a powerful, robust bike that pays tribute to the original G/S design: the 19-inch front wheel, the telescopic fork with the familiar bellows, the headlamp mask with the windscreen and the raised front-wheel cover define the front of the bike. The profile is defined by a pronounced horizontal line. White body elements and the narrow, slightly longer red seat revive the spirit of the legendary R 80 G/S from 1980. The black engine and frame highlight this effect. The new classic round instruments also show that the Urban G/S is part of the R nineT family. The R nineT Urban G/S also excels on everything from unpaved paths to gravel roads. The optional knubby tires and spoked wheels, the Enduro foot pegs, the bolted-on heat shield and the steel footbrake lever emphasize the effect, both functionally and visually. Technology for pure riding fun. The R nineT Urban G/S is faithful to tradition with its looks, but the bike shows equal respect for the present with its modern technology. It features the proven engine and electrical system of the BMW R nineT. The Urban G/S also meets the current EU-4 emission standard. The powerful air-cooled, two-cylinder boxer engine features a capacity of 1170 ccm+ and 110 hp (81 kW) of output for a highly dynamic power delivery, even at low speeds. All for a light and modern riding experience. The standard ABS and optional ASC Automatic Stability Control help confidence in a range of riding conditions. And there’s one last visual reference to the enduro roots of the G/S: the raised exhaust system made of brushed stainless steel. Upright and majestic. The balanced ergonomic triangle of the Urban G/S keeps you agile and confident on the road: The slightly higher handlebar, the long seat surface and slightly deeper and wider rear mounted footrests make for a more relaxed and confident riding experience. The standard seat height of the series is 33.5”. Thanks to an optional lower seat, the R nineT Urban G/S offers stability for riders of almost all sizes. Customizing almost without limits. When it comes to customizing, the possibilities are almost endless, as showcased so well in countless adventures throughout G/S history. The R nineT Urban G/S can be quickly converted into a one-seater thanks to the removable pillion frame. There’s also a tailored range of Original BMW Motorrad accessories to choose from. Options include a crash bar, engine guard or protective headlamp grille. The bike also comes with several optional accessories, including spoked wheels, various tanks, ASC (Automatic Stability Control), heated grips or LED turn indicators. But the R nineT Urban G/S is also ideal for installing specially fabricated add-on components such as our new Machined parts. In short: Your individuality is just as unrestricted as your riding pleasure. The new R nineT and R nineT Urban G/S: refined roadster with boutique manufacturing character and boxer feeling in a classic enduro outfit. 2018 BMW R nineT Urban G/S Key Features • Potent flat-twin boxer engine with a capacity of 1 170 cc and an output of 81 kW (110 hp) that meets EU4 requirements. • Modular frame concepts with scope for customising, allowing individualisation according to personal taste. • R nineT with new wired-spoke wheels. • R nineT Urban G/S with light alloy cast wheels and 19-inch front wheel in enduro style. • 320-millimetre twin disc brake at the front. • ABS as standard. • ASC (Automatic Stability Control) as an ex works option. • 2-in-1 exhaust system. • High-end details such as fork bridges made of forged aluminium with a clear anodised finish. • R nineT in classic roadster design in Blackstorm metallic in conjunction with a black frame and drivetrain. • R nineT Urban G/S in the enduro style of the first R 80 G/S dating back to the year 1980. • R nineT Urban G/S in Lightwhite non-metallic combined with fuel tank decor in two blue tones with a bright red seat – echoing BMW Motorsport colours of past years.
