| MODEL | BMW R 1150R 2005 - 2006 |
| Year | 2005 - 2006 |
| Engine Type | Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder |
| Displacement / Capacity | 1130 cc / 69 cu in |
| Bore X Stroke | 101 x 70.5 mm |
| Compression Ratio | 10.3:1 |
| Cooling System | Air/Oil cooled |
| Max Power | 62 kW / 85 hp @ 6750 rpm |
| Max Torque | 98 Nm / 72.3 ft-lb @ 5250 rpm |
| Ignition | Bosch Motronic MA 2.4 engine management with dual (twin-spark) ignition |
| Induction | Bosch Motronic MA 2.4 fuel injection |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Wet sump |
| Gear Box | 6 Speed |
| Clutch | Dry, single plate, hydraulically operated |
| Final Drive | Shaft |
| CHASSIS SPECS | |
| Frame | Three section composite frame consisting of front & rear section, load bearing engine |
| Front Suspension | BMW Telelever with central spring strut, twin-tube gas-filled shock, 120 mm / 4.7 in travel |
| Rear Suspension | BMW Paralever swingarm, single-tube gas-filled shock, variable rebound setting, 135 mm / 5.3 in travel |
| Front Brakes | 2 x 320 mm discs, 4 piston calipers |
| Rear Brakes | Single 276 mm disc, 2 piston caliper |
| DIMENSION SPECS | |
| Overall Length | 2170 mm / 85.4 in |
| Overall Width | 940 mm / 37.0 in |
| Overall Height | 1220 mm / 48.0 in |
| Seat Height | 800 mm / 31.5 in (low seat 770 mm / 30.3 in) |
| Wheelbase | 1487 mm / 58.5 in |
| Ground Clearance | — |
| Dry Weight | 218 kg / 480 lbs |
| Wet Weight | 238 kg / 524.7 lbs |
| WHEEL SPECS | |
| Front Tyre | 120/70 ZR17 |
| Rear Tyre | 170/60 ZR17 |
| FUEL SYSTEM | |
| Fuel Capacity | 20.4 Litres / 5.4 US gal |
| Fuel Consumption | 5.56 L/100 km / 42.3 US mpg |
| Top Speed | 197 km/h / 122 mph |
The last R 1150 R models ran out the 1150 boxer before the lighter R 1200 R replaced it. By now the engine used dual-spark ignition with Motronic MA 2.4 management, but output, chassis and dimensions stayed as before, making these final bikes the most refined of the run.
