BMW

BMW R1200 GS LC ADVETURE 2018

2018 BMW R 1200 GS LC ADVENTURE FACTORY SPECIFICATIONS
2018 BMW R 1200 GS LC ADVENTURE FACTORY SPECIFICATIONS
Spec sheet
MODELBMW R 1200 GS LC ADVENTURE
ENGINE TYPEFour stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder, Intake 40mm, outlet 34 mm
Year2018
Displacement / Capacity1170 cc / 71.4 cub in.
Bore X Stroke101 x 73 mm
Compression Ratio12.5:1
Cooling SystemLiquid / Air cooled
Max Power92 kW / 125 hp @ 7750  rpm
Max Torque125 Nm /12.7 kgf-m / 92 lb-ft @ 6500 rpm
IgnitionBMS-K
InductionElectronic intake pipe injection
Start SystemElectric
TRANSMISSION SPECS
Lubrication—
Gear BoxConstant-mesh 6-speed gearbox
ClutchOil lubricated, hydraulically operated
Primary / Final DriveFinal Drive : Shaft / Primary Drive :
Transmission Ratio2.91:1
Gear Ratio1st 2.438 / 2nd 1.714 / 3rd 1.296 / 4th 1.059 / 5th 0.943 / 6th 0.848:1
CHASSIS SPECS
FrameTwo-section frame, front- and bolted on rear frame, load-bearing engine
Front SuspensionBMW Motorrad Telelever; standpipe diameter 37 mm, central spring strut
Rear SuspensionCast aluminium single swinging arm with BMW Motorrad Paralever; WAD spring strut, variable / spring preload hydraulically adjustable by adjuster knob, rebound-stage damping adjustable by knob.
BrakesFront Brakes: 305mm Hydraulically actuated twin disc brake, BMW Motorrad Integral ABS Pro, disengageable / / Rear Brakes : Single 275mm disc, 2 piston caliper, BMW Motorrad Integral ABS Pro, disengageable
Traction Management—
Exhaust SystemFully-controlled three-way catalytic converter
DIMENSION SPECS
Overall Length2207 mm / 86.9 in
Seat Height850 mm - 870 mm (OE low suspension 800 mm / 820 mm)<
Overall Height1412 mm / 55.6 in (excl. mirrors)
Overall Width953 mm / 37.5 in (incl. mirrors)
Overall WeightDry Weight - / Wet Weight - 244 Kg / 538 lbs
Wheelbase1507 mm / 59.3 in.
Inner Leg Curve—
WHEEL SPECSCast aluminum wheels and spokes or laced wire spokes
Wheels / RimsFront Riml : 3.00 x 19 in. / Rear Rim: 4.50 x 17 in. /
Front Tyre120/70 R19
Rear Tyre170/60 R 17
Front Wheel Travel190 mm / 7.4 in
Rear Wheel Travel200 mm / 7.28 in
Castor99.6 mm / 3.9 in.
Steering Angle64.5
FUEL SYSTEMUnleaded super, octane number 95 (RON)
Fuel Capacity20 Litres / 5.3 US gal / 4.4 Imp gal
Fuel Reserve4 Litres / 1.0 US gal / 0.9 Imp gal
Fuel Consumption4.96 litres/100 km (20.2 km/l or 47.42 mpg)
CAPACITIES
Engine oil—
Brake fluid—
Top Speed125 mph
Photo gallery
BMW R 1200 GS LC ADVENTURE FACTORY SPECIFICATIONS BMW R 1200 GS LC ADVENTURE FACTORY SPECIFICATIONS BMW R 1200 GS LC ADVENTURE FACTORY SPECIFICATIONS 2017 / 2018 BMW R 1200 GS LC RALLYE
BMW file

Since its advent in 1923, BMW’s opposed-twin (“boxer”) engine has occupied an odd spot in motorcycling. BMW gave its R 1200 GS a series of tweaks over the past couple of years to deliver a more polished product than ever before Its cylinder heads protrude into a cooling airflow and protect feet from cold and possibly impacts. On the downside, they can limit cornering clearance and deliver a nasty smack to the shin bones when you’re, say, paddling through sand. And this dichotomy makes the best-selling R1200GS ADV’s success all the more remarkable. The current R1200GS descends from BMW’s original 1980 R80 G/S adventure bike. Combining liquid-cooling for the first time in division history, it also represented the highest-tech Bavarian boxer to date. The 1,170cc DOHC eight-valve engine produces a claimed 125 hp at a reasonable 7,700 rpm—plenty to shove the 525-pound machine down the road quickly. Its 180-degree crankshaft grants tractable power, while a balance shaft improves smoothness. The Adventure version adds wire-spoked wheels, 0.8 inch more suspension travel, a 49 percent larger (7.9-gallon) fuel tank, a flatter seat, crash bars, and unique finishes. The R1200GS has a 3-foot-high air intake just right for fording streams! 2018 BMW R 1200 GS Adventure Colors: Racing Red Light White/Cordoba Blue Black Storm Metallic/Dark Slate Metallic Matte/Achat Grey
