2018 BMW R1200 GS RALLYE FACTORY SPECIFICATIONS
2018 BMW R1200 GS RALLYE FACTORY SPECIFICATIONS
Spec sheet
MODELBMW R 1200 GS LC RALLYE
ENGINE TYPEFour stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder, Intake 40mm, outlet 34 mm
Year2017 / 2018
Displacement / Capacity1170 cc / 71.4 cub in.
Bore X Stroke101 x 73 mm
Compression Ratio12.5:1
Cooling SystemLiquid / Air cooled
Max Power92 kW / 125 hp @ 7750  rpm
Max Torque125 Nm /12.7 kgf-m / 92 lb-ft @ 6500 rpm
IgnitionBMS-K
InductionElectronic intake pipe injection
Start SystemElectric
TRANSMISSION SPECS
Lubrication—
Gear BoxConstant-mesh 6-speed gearbox
ClutchOil lubricated, hydraulically operated
Primary / Final DriveFinal Drive : Shaft / Primary Drive :
Transmission Ratio2.91:1
Gear Ratio1st 2.438 / 2nd 1.714 / 3rd 1.296 / 4th 1.059 / 5th 0.943 / 6th 0.848:1
CHASSIS SPECS
FrameTwo-section frame, front- and bolted on rear frame, load-bearing engine
Front SuspensionBMW Motorrad Telelever; standpipe diameter 37 mm, central spring strut
Rear SuspensionCast aluminium single swinging arm with BMW Motorrad Paralever; WAD spring strut, variable / spring preload hydraulically adjustable by adjuster knob, rebound-stage damping adjustable by knob.
BrakesFront Brakes: 305mm Hydraulically actuated twin disc brake, BMW Motorrad Integral ABS Pro, disengageable / / Rear Brakes : Single 275mm disc, 2 piston caliper, BMW Motorrad Integral ABS Pro, disengageable
Traction Management—
Exhaust SystemFully-controlled three-way catalytic converter
DIMENSION SPECS
Overall Length2207 mm / 86.9 in
Seat Height850 mm - 870 mm (OE low suspension 800 mm / 820 mm)<
Overall Height1412 mm / 55.6 in (excl. mirrors)
Overall Width953 mm / 37.5 in (incl. mirrors)
Overall WeightDry Weight - / Wet Weight - 244 Kg / 538 lbs
Wheelbase1507 mm / 59.3 in.
Inner Leg Curve—
WHEEL SPECSCast aluminum wheels and spokes or laced wire spokes
Wheels / RimsFront Riml : 3.00 x 19 in. / Rear Rim: 4.50 x 17 in. /
Front Tyre120/70 R19
Rear Tyre170/60 R 17
Front Wheel Travel190 mm / 7.4 in
Rear Wheel Travel200 mm / 7.28 in
Castor99.6 mm / 3.9 in.
Steering Angle64.5
FUEL SYSTEMUnleaded super, octane number 95 (RON)
Fuel Capacity20 Litres / 5.3 US gal / 4.4 Imp gal
Fuel Reserve4 Litres / 1.0 US gal / 0.9 Imp gal
Fuel Consumption4.96 litres/100 km (20.2 km/l or 47.42 mpg)
CAPACITIES
Engine oil—
Brake fluid—
Top Speed125 mph
Photo gallery
2017 / 2018 BMW R 1200 GS LC RALLYE 2017 / 2018 BMW R 1200 GS LC RALLYE 2017 / 2018 BMW R 1200 GS LC RALLYE 2017 / 2018 BMW R 1200 GS LC RALLYE 2017 / 2018 BMW R 1200 GS LC RALLYE photo 2017 / 2018 BMW R 1200 GS LC RALLYE 2017 / 2018 BMW R 1200 GS LC RALLYE
BMW file

BMW Motorrad introduced the latest versions of the R1200 GS, the Rallye and the Exclusive, in April 2017. The launch took the form of a tarred routein a Nature Reserve, and a return trip mostly on gravel roads – a route that allowed us to explore the bikes properly and answer the one big question: is it any different from the previous version? BMW says that the R1200 GS has now been optimised in a wide range of areas with selective improve-ments, new features and an expanded program of optional equipment and optional accessories. The new models retain the 92 kW air/liquid-cooled boxer motor with 125 Nm of torque at 6 500 rpm,but it sports an altered catalytic converter and a new data status for the engine management to meet the latest EU 4 requirements. In addition to the existing two riding modes, Rain and Road” new R 1200 GS also comes standard with Riding Modes Pro which adds “Dynamic”, “Dynamic Pro”, “Enduro” and “Enduro Pro” to the standard package. It also comes with bank-angle aware Dynamic Traction Control (DTC), as well as Automatic Stability Control (ASC) for optimum traction. One of the big changes is the availability of the optional Dy-namic Electronic Suspension Adjustment (ESA), which includes an automatic self-levelling function to compensate for all load states. The bikes also feature quick-shifters (BMW Gear Shift Assist Pro). BMW describe the Rallye version as the sportiest GS, with a number of unique details such as a low-cut sports windshield, stainless steel radiator trim, a radiator guard, wide enduro footrests and a special frame guard to protect the section of the suspension in the boot area from unwanted scrape marks. In Exclusive guise, the new R 1200 GS comes with a much more sober paint scheme and fuel tank side trim panels to give it a distinguished look. There are three settings for the ESA: minimum, maximum and automatic. While surrounded by competitors that offer more than the 1200 GS in one or two specific areas, the big Beemer remains the benchmark against which adventure bikes are measured because of its all-round versatility – from commuting to high-speed touring to serious off-road riding, the GS adapts without so much as a second thought. And that means that if you look beyond a champion feature or two, there are few bikes that can challenge the R1200 GS for its Swiss Army knife-like utility.
