2019 BMW R 1250 GS ADVENTURE FACTORY SPECIFICATIONS
2019 BMW R 1250 GS ADVENTURE FACTORY SPECIFICATIONS
Spec sheet
MODELBMW R 1250 GS ADVENTURE
ENGINE TYPEFour stroke, two cylinder horizontally opposed Boxer, with two overhead, spur gear driven camshafts , a counterbalance / shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, Intake 40mm, outlet 34 mm
Year2019 / 2020 /
Displacement / Capacity1254 cc / 76.5 cu-in
Bore X Stroke102.5 x 76 mm
Compression Ratio12.5:1
Cooling SystemLiquid / Air cooled
Max Power136 hp / 100 kW @ 7750 rpm
Max Torque143 Nm / 105.4 lb-ft @ 6250 rpm
Engine ControlBMS-O
InductionElectronic intake pipe injection, 52mm Ø throttle valve
Start SystemElectric
TRANSMISSION SPECS
Lubrication—
Gear BoxConstant mesh 6-speed gearbox with helical gearing system
ClutchWet clutch with anti-hopping function, hydraulically activated
Primary / Final DriveFinal Drive : Shaft / Primary Drive :
Primary Ratio1.650
Gear Ratio1st 2.438 / 2nd 1.714 / 3rd. 1.296 / 4th 1.059 / 5th 0.943 / 6th 0.848
CHASSIS SPECS
FrameTwo-section frame concept consisting of main frame with bolt-on rear frame, load-bearing engine
Front SuspensionBMW Motorrad 37mm Telelever, central spring strut
Rear SuspensionCast aluminium single-sided swing arm with BMW Motorrad Paralever, WAD spring strut, continuously adjustable spring / preload by means of hand wheel, rebound-stage damping adjustable by hand wheel. / (Option: Dynamic ESA)
BrakesFront Brakes: 2x 305mm floating discs, 4-piston radial brake calipers / / Rear Brakes : Single 276mm disc, 2-piston floating caliper / / ABS System : BMW Motorrad Integral ABS as standard (part integral), disengageable
Traction Management—
Exhaust SystemClosed-loop three-way catalytic converter, exhaust standard , Euro 4
DIMENSION SPECS
Overall LengthLength 2270 mm / 89.4 in
Seat Height850 mm to 870 mm / 33.5 in to 34.3 in / 800 mm to 900 mm / 31.5 in to 35.4 in - Optional
Overall Height—
Overall Width952.5 mm / 37.5 in
Overall WeightDry Weight - / Wet Weight - 268 kg / 591 lbs
Wheelbase1504 mm / 59.2 in
Inner Leg Curve—
WHEEL SPECSCross spoke
Wheels / RimsFront Wheel : 3.00 x 19 in / Rear Wheel: 4.50 x 17 in /
Front Tyre120/70 R19
Rear Tyre170/60 R17
Front Wheel Travel210 mm / 8.26 in
Rear Wheel Travel220 mm / 8.7 in
Castor95.4 mm / 3.8 in
Steering Angle65.1°
FUEL SYSTEMUnleaded super, octane number 95 (RON)
Fuel Capacity30 Litres / 7.9 US gal
Fuel Reserve—
Fuel Consumption—
CAPACITIES
Engine oil—
Brake fluid—
Top Speed+- 130.8 mph / 210.5 km/h
Photo gallery
2019 BMW R 1250 GS ADVENTURE 2020 BMW R 1250 GS ADVENTURE 2020 BMW R 1250 GS ADVENTURE SPECS 2020 BMW R 1250 GS ADVENTURE SPECS 2020 BMW R 1250 GS ADVENTURE SPECS 2020 BMW R 1250 GS ADVENTURE SPECS 2020 BMW R 1250 GS ADVENTURE SPECS 2020 BMW R 1250 GS ADVENTURE SPECS
BMW file

The BMW R 1250 GS Adventure is built for your challenges. Rough routes, adverse conditions and the most remote destinations are no problem for the queen of travel enduros. With 1,254 cc and 136 hp, you have more than enough power for wilderness, desert or country road. In addition to the performance, the engine also gives you the endurance you need in order to reach the next stage finish. The variable camshaft control BMW ShiftCam offers you power in every engine speed range and gives the Boxer engine an unprecedented culture. No matter what adventure drives you, the BMW R 1250 GS Adventure is ready to go with you. All variants have a robust appearance with cross-spoked wheels, engine protection bars and hand protectors. Each style has individual details and visually sets a statement. With the basic version, you show cool elegance in Ice Grey. The Style Exclusive makes a sturdy and confident figure, and with the Style HP you underline your claim to performance in motorsport colors. Ice Grey The color Ice Grey gives the basic model a special appearance on the road as well as on the terrain. The main frame and handlebars are silver, the drivetrain, the cross-spoked wheels, the black hand protector and the brake calipers black, and the seat red and black, creating attractive contrasts. Light White, Racing Blue Metallic and Racing Red With Style HP, the R 1250 GS Adventure is particularly sporty. The dynamic color combination in Light White, Racing Blue Metallic and Racing Red is eye-catching. The HP logo, large colored tapes and high-quality hardware components round off the sporty appearance. Kalamata Metallic Matte In Style Exclusive, the bike features an elegant and expressive paintwork in Kalamata Metallic Matte. There are also premium materials and surfaces. The exclusive lettering, large colored tapes and high-quality hardware components round off the stylish appearance. BMW Motorrad is entering new territory with the BMW ShiftCam variable camshaft control system. What does this mean for you? That means smoother running in the low speed range and high torque in each speed range. This results in a balanced engine running that gives you even more confidence when riding your R 1250 GS Adventure. This performance is clearly noticeable on any terrain with 136 hp and 105 lb-ft max. torque at 6,250 rpm. The high torque curve, the elasticity with impressive sprint qualities and the sovereign acceleration let you experience your adventures with even more intensity. The BMW ShiftCam ensures an optimal combustion process and thus an overall increase in energy efficiency. SOURCE : bmwmotorcycles.com
