| MODEL | BMW R NINE T SCRAMBLER |
| ENGINE TYPE | Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, / central counter balancer shaft. |
| Year | 2020 |
| Displacement / Capacity | 1170 cc / 71.4 cub in. |
| Bore X Stroke | 101 x 73 mm |
| Compression Ratio | 12.0:1 |
| Cooling System | Air / Oil cooled |
| Max Power | 81 kW / 110 hp @ 7550 rpm |
| Max Torque | 116 Nm / 11.8 kgf-m / 85.6 lb-ft @ 6000 rpm |
| Ignition | — |
| Induction | Electronic intake pipe injection / digital engine management with overrun cutoff, twin-spark ignition |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Wet sump |
| Gear Box | Constant mesh 6-speed |
| Clutch | Single dry plate clutch, hydraulically operated |
| Primary / Final Drive | Final Drive : Shaft / Primary Drive : |
| Secondary drive | — |
| Gear Ratio | Ist 2.375 / 2nd 1.696 / 3rd 1.296 / 4th 1.065 / 5th 0.939 / 6th 0.848:1 |
| CHASSIS SPECS | |
| Frame | Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame / removeable for one-up riding |
| Front Suspension | Upside-down telescopic forks, 46 mm fixed-fork-tube diameter |
| Rear Suspension | Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring / strut,spring preload fully adjustable by hook wrench, adjustable rebound-stage damping |
| Brakes | Front Brakes: 2 x 320 mm Foating brake discs, 4 piston radial calipers / / Rear Brakes : Single 265 mm disc, 2 piston floating caliper / / ABS : BMW Motorrad ABS |
| Traction Management | — |
| Exhaust System | Closed-loop 3-way catalytic converter, emission standard EU-3 |
| DIMENSION SPECS | |
| Overall Length | 2175 mm / 85.6 in |
| Seat Height | 820 mm / 32.3 in |
| Overall Height | 1330 mm / 52.3 in |
| Overall Width | 880 mm / 34.6 in (incl. mirrors) |
| Overall Weight | Dry Weight - / Wet Weight - 220 kg / 485 lbs |
| Wheelbase | 1522 mm / 60.1 in |
| Inner Leg Curve: | 1830 mm / 72 in |
| WHEEL SPECS | |
| Wheels / Rims | Front Rim : 3.00 x 19, Cast alloy / Rear Rim: 4.50 x 17, Cast alloy / |
| Front Tyre | 120 / 70 - R19 |
| Rear Tyre | 170 / 60 - R17 |
| Front Wheel Travel | 125 mm / 4.9 in |
| Rear Wheel Travel | 140 mm / 5.5 in |
| Castor | 116.1 mm / 4.4 in |
| Steering Angle | 61.5 ° |
| FUEL SYSTEM | |
| Fuel Capacity | 17 Litres / 4.5 US gal / 3.7 Imp gal |
| Fuel Reserve | Approx. 3.5 Litres / 1 gal |
| Fuel Consumption | 5.9 L/100 km; 48 mpg‑imp (40 mpg‑US) |
| CAPACITIES | |
| Engine oil | — |
| Brake fluid | — |
| Top Speed | 125 mph (Est) |
THONEST. UNTAMED. AIR COOLED. Feel the wind, lean into every curve and experience the freedom in every mile you ride – the BMW R nineT Scrambler empowers you to do your own thing. It’s rugged bike with an authentic scrambler look, combined with the innovative technology and familiar quality of BMW Motorrad. Whether in the city, on winding country roads or on the beach, the potent opposed-twin engine and high-positioned dual silencers deliver powerful acceleration and an unmistakable sound. Even long trips with two people are a breeze thanks to the relaxed seating position. In just a few steps you can also give your R nineT Scrambler your own personal touch. Choose your style. Your motorcycle, your choice: There are three different paint colors for the R nineT Scrambler. Choose between Stereo Metallic Matte or the two BMW Motorrad Option 719 finishes - Option 719 Black Storm Metallic/Aurum and Option 719 Black Storm Metallic/Light White. Typical Scrambler. The R nineT Scrambler harks back to the legendary scrambler era and has all the hallmarks of this extraordinary type of motorcycle: a telescopic fork with bellows, a distinctive raised exhaust and a large 19-inch front wheel. The compact steel tank in Monolith Metallic Matte highlights the puristic look.The seat in leather style and the tachometer with analog display are also eye-catchers. High-quality details like the round headlights with BMW emblem make this classic heritage bike look perfect. Powerful boxer for dynamic riding fun. The engine and electrical system are already proven components of the BMW R nineT. The beefy, air-cooled twin-cylinder boxer engine features a capacity of 1,170 cc and 110 hp of output for a highly dynamic riding experience. Thanks to standard ABS and ASC (Automatic Stability Control) you can take this power safely to the streets any time. Casual Scrambler feeling. A relaxed upright seated riding position is one of the key features of a scrambler. It not only looks laid back, it also makes for a relaxed ride feel. Even long rides to the nearest beach are a breeze thanks to the bike's higher handlebars as compared with the R nineT, slightly reduced seat cushioning and footrests that are positioned somewhat lower and further to the rear. Source: bmwmotorcycles.com
