| MODEL | DUCATI 907IE 1991 - 1992 |
| Year | 1991 - 1992 |
| Engine Type | Four stroke, 90° V-twin, SOHC, desmodromic, 2 valves per cylinder, belt driven |
| Displacement / Capacity | 904 cc / 55.2 cu in |
| Bore X Stroke | 92 x 68 mm |
| Compression Ratio | 9.2:1 |
| Cooling System | Liquid cooled |
| Max Power | 66.2 kW / 90 hp @ 8500 rpm |
| Max Torque | 77 Nm / 57 lb-ft @ 6750 rpm |
| Ignition | Marelli Digiplex, variable advance |
| Induction | Weber-Marelli IAW 043 integrated electronic fuel injection and ignition |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6 speed |
| Clutch | Dry, multiplate |
| Final Drive | Chain, 2.666:1 (15/40) |
| CHASSIS SPECS | |
| Frame | Rectangular-section steel double cradle |
| Front Suspension | 42 mm Marzocchi M1R oil-dynamic fork, external rebound adjustment |
| Rear Suspension | Swingarm with Marzocchi Duoshock adjustable oil-dynamic monoshock |
| Front Brakes | 1991: 2 x 300 mm discs; 1992: 2 x 320 mm discs; 2-piston calipers |
| Rear Brakes | Single 245 mm disc, 1-piston caliper |
| DIMENSION SPECS | |
| Overall Length | 2090 mm / 82.3 in |
| Overall Width | 700 mm / 27.6 in |
| Overall Height | 1160 mm / 45.7 in |
| Seat Height | 780 mm / 30.7 in |
| Wheelbase | 1490 mm / 58.7 in |
| Ground Clearance | — |
| Dry Weight | 215 kg / 474 lb |
| Wet Weight | — |
| WHEEL SPECS | |
| Front Tyre | 120/70-17 |
| Rear Tyre | 170/60-17 |
| FUEL SYSTEM | |
| Fuel Capacity | 21 Litres / 5.5 US gal |
| Fuel Consumption | 5.6 L/100 km / 42 US mpg |
| Top Speed | 221.8 km/h / 137.8 mph |
The 907 i.e. replaced the 906 Paso in 1991 and borrowed engine and chassis ideas from the 851, including Weber-Marelli fuel injection, a revised clutch, stronger crankcases and a longer aluminium swingarm. It moved to 17-inch wheels and kept the Paso's double-cradle steel frame and enclosing bodywork. The 1992 bike got larger front discs and gold Brembo calipers, but sales were poor and it ended that year.
