| MODEL | DUCATI DIAVEL CARBON 2014 |
| Year | 2014 |
| Engine Type | Four stroke, 90° L-twin, DOHC, desmodromic, 4 valves per cylinder (Testastretta 11°) |
| Displacement / Capacity | 1198.4 cc / 73.1 cu in |
| Bore X Stroke | 106 x 67.9 mm |
| Compression Ratio | 11.5:1 |
| Cooling System | Liquid cooled |
| Max Power | 119 kW / 162 hp @ 9500 rpm |
| Max Torque | 127.5 Nm / 94 lb-ft @ 8000 rpm |
| Ignition | Marelli electronic |
| Induction | Mitsubishi electronic fuel injection, Mikuni elliptical throttle bodies with ride-by-wire |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6-speed |
| Clutch | Wet multiplate, hydraulic control, self-servo on drive, slipper action on over-run |
| Final Drive | Chain, 15T front / 43T rear sprocket |
| CHASSIS SPECS | |
| Frame | Tubular steel trellis |
| Front Suspension | Marzocchi 50 mm fully adjustable USD fork, 120 mm / 4.7 in travel |
| Rear Suspension | Progressive linkage, fully adjustable Sachs monoshock, aluminium single-sided swingarm, 120 mm / 4.7 in travel |
| Front Brakes | 2 x 320 mm semi-floating discs, radial Brembo 4-piston monobloc calipers, ABS |
| Rear Brakes | Single 265 mm disc, 2-piston floating caliper, ABS |
| DIMENSION SPECS | |
| Overall Length | 2235 mm / 87.9 in |
| Overall Width | 860 mm / 33.8 in |
| Overall Height | 1192 mm / 46.9 in |
| Seat Height | 770 mm / 30.3 in |
| Wheelbase | 1590 mm / 62.6 in |
| Ground Clearance | — |
| Dry Weight | 205 kg / 452 lb |
| Wet Weight | — |
| WHEEL SPECS | |
| Front Tyre | 120/70 ZR17 |
| Rear Tyre | 240/45 ZR17 |
| FUEL SYSTEM | |
| Fuel Capacity | 17 Litres / 4.5 US gal |
| Fuel Consumption | 5.2 L/100 km / 45.6 US mpg |
| Top Speed | 252.4 km/h / 156.8 mph |
The Diavel Carbon was the up-market 2014 version with gloss red paint over exposed carbon fibre, red frame and black forged Marchesini wheels. Carbon covers the tank panels, seat cover and front mudguard, and the lighter wheels cut around 2.5 kg of unsprung weight. Engine and electronics are the same as the standard Diavel.
