| MODEL | DUCATI SCRAMBLER 800 DESERT SLED 2020 |
| Year | 2020 |
| Engine Type | Air-cooled 90° L-twin, 4-stroke, SOHC, Desmodromic, 2 valves per cylinder |
| Displacement / Capacity | 803 cc / 49.0 cu in |
| Bore X Stroke | 88 x 66 mm |
| Compression Ratio | 11.0:1 |
| Cooling System | Air-cooled |
| Max Power | 54 kW / 73 hp @ 8250 rpm |
| Max Torque | 67 Nm / 49 lb-ft @ 5750 rpm |
| Ignition | Electronic (Marelli) |
| Induction | Electronic fuel injection, 50 mm throttle body |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6-speed |
| Clutch | Hydraulic wet multiplate, slipper and self-servo |
| Final Drive | Chain, 15T front / 46T rear sprockets |
| CHASSIS SPECS | |
| Frame | Tubular steel trellis frame |
| Front Suspension | 46 mm Kayaba upside-down fork, 200 mm / 7.9 in travel |
| Rear Suspension | Kayaba shock, preload adjustable, 200 mm / 7.9 in travel |
| Front Brakes | 330 mm disc, radial 4-piston caliper, Bosch Cornering ABS |
| Rear Brakes | 245 mm disc, 1-piston floating caliper |
| DIMENSION SPECS | |
| Overall Length | 2200 mm / 86.6 in |
| Overall Width | 940 mm / 37.0 in |
| Overall Height | 1213 mm / 47.8 in |
| Seat Height | 860 mm / 33.9 in |
| Wheelbase | 1505 mm / 59.3 in |
| Ground Clearance | — |
| Dry Weight | 193 kg / 425 lb |
| Wet Weight | 209 kg / 461 lb |
| WHEEL SPECS | |
| Front Tyre | 120/70 R19 Pirelli Scorpion Rally STR |
| Rear Tyre | 170/60 R17 Pirelli Scorpion Rally STR |
| FUEL SYSTEM | |
| Fuel Capacity | 13.5 Litres / 3.57 US gal |
| Fuel Consumption | — |
| Top Speed | — |
The 2020 Desert Sled carries over the updated 2019 package: red trellis frame, 200 mm suspension, cornering ABS that can be switched off in the Off Road mode, LED lighting and an LCD dash. It revives the 1960s-70s American desert-sled look with a headlight mesh guard, high mudguards and a skid plate.
