| MODEL | Ducati XDiavel |
| ENGINE TYPE | Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, / dual spark |
| Year | 2017 - 2018 |
| Displacement / Capacity | 1262 cc / 77 cu in |
| Bore X Stroke | 106 x 71.5 mm |
| Compression Ratio | 13.0:1 |
| Cooling System | Liquid Cooled |
| Max Power | 114.7 kW / 156 hp @ 9500 rpm |
| Max Torque | 128.9 Nm / 13.1 kgf-m / 95 lb-ft @ 5000 rpm |
| Ignition | Electronic |
| Induction | BOSCH fuel injection system, full ride-by-wire system, 56mm oval throttle bodies |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6 Speed |
| Clutch | Slipper and self-servo wet multiplate clutch with hydraulic control |
| Primary / Final Drive | Final Drive : Belt; Front sprocket Z28; Rear sprocket Z80 / Primary Drive : Straight cut gears, 1,84:1 ratio |
| Secondary drive | — |
| Gear Ratio | 1st 37:15 / 2nd 30:17 / 3rd 27:20 / 4th 24:22 / 5th 23:24 / 6th 22:25 |
| CHASSIS SPECS | |
| Frame | Tubular steel trellis frame |
| Front Suspension | Adjustable Ø 50 mm (Ø 1,97 in) usd fork with DLC treatment |
| Rear Suspension | Single shock absorber, Adjustable preload and rebound, Remote reservoir. Single sided swingarm, Cast/trellis frame |
| Brakes | Front Brakes: 2x 320 mm semifloating discs, radial Brembo monobloc 4-piston M4-32 callipers and radial master cylinder / / Rear Brakes : 265 mm (10,43 in) Disc, 2-piston floating calliper. BOSCH cornering ABS as standard equipment / / ABS: BOSCH cornering ABS as standard equipment |
| Traction Management | — |
| Exhaust System | BOSCH fuel injection system, Full ride-by-wire system, DEQ 56 oval throttle bodies |
| DIMENSION SPECS | |
| Overall Length | 2235 mm (88.0 inches) |
| Seat Height | 755 mm (29.7 inches) If adjustable, lowest setting. |
| Overall Height | — |
| Overall Width | — |
| Overall Weight | Dry Weight - 220 kg / 485 lbs / Wet Weight - 247 kg / 545 lbs |
| Wheelbase | 1615 mm / 63.6 in |
| Inner Leg Curve | — |
| WHEEL SPECS | |
| Wheels / Rims | Front Wheel : Light alloy, Cast and machined, 3.50 x 17 / Rear Wheel: Light alloy, Cast and machined, 8.00 x 17 / |
| Front Tyre | Pirelli Diablo Rosso II, 120/70 ZR17 |
| Rear Tyre | Pirelli Diablo Rosso II 240/45 ZR17 |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Wheel Travel | 110 mm / 4.33 in |
| Rake: | 30.0° |
| Trail | 130 mm / 5.1 in |
| FUEL SYSTEM | Injection. Bosch fuel injection system. Full ride-by-wire system. |
| Fuel Capacity | 17.00 litres (4.49 gallons) |
| Fuel Reserve | — |
| Fuel Consumption | 5.30 litres/100 km (18.9 km/l or 44.38 mpg) |
| ADDITIONAL | |
| Top Speed | 150 mph (est) |
| Instrumentation | — |
| Standard Equipment | — |
