| MODEL | Ducati Monster 797 |
| ENGINE TYPE | L-Twin, 2 Desmodromically actuated valves per cylinder, Air cooled |
| Year | 2020 |
| Displacement / Capacity | 803 cc / 49.0 cu in |
| Bore X Stroke | 88mm x 66 mm |
| Compression Ratio | 11.0:1 |
| Cooling System | Air Cooled |
| Max Power | 73 hp (54 kW) @ 8250 rpm |
| Max Torque | 49 lb-ft (67 Nm) @ 5750 rpm |
| Ignition | Electronic fuel injection system, Ø 50 throttle bodies |
| Induction | — |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6 Speed |
| Clutch | APTC wet multiplate clutch with mechanical control |
| Primary / Final Drive | Final Drive : Chain. Front Sprocket Z15, Rear Sprocket Z46 / Primary Drive : Straight Cut Gears, Ratio 1.85:1 |
| Secondary drive | — |
| Gear Ratio | 1st 32/13 2nd 30/18 3rd 28/21 4th 26/23 5th 22/22 6th 24/26 |
| CHASSIS SPECS | |
| Frame | Tubular steel trellis |
| Front Suspension | Ø 43 Kayaba usd fork, 5.12 in. travel |
| Rear Suspension | Sachs monoshock, Pre-load and rebound adjustable |
| Brakes | Front Brakes: 2 x Ø 320mm semi-floating discs, radially mounted monoblock Brembo M4.32 callipers, 4-piston, axial pump / / Rear Brakes : Ø 245mm disc, 1-piston calliper / / ABS: Bosch ABS Standard Equipment |
| Traction Management | — |
| Exhaust System | 2-1 system with catalytic converter and two lambda probes, Single stainless steel muffler with aluminum cover |
| DIMENSION SPECS | |
| Overall Length | — |
| Seat Height | 805 mm / 31.6 in |
| Overall Height | — |
| Overall Width | — |
| Overall Weight | Dry Weight - 175 kg / 386 lbs / Wet Weight - 193 kg / 425 lbs |
| Wheelbase | 1435 mm / 56.5 in |
| Inner Leg Curve | — |
| WHEEL SPECS | |
| Wheels / Rims | Front Wheel : 10-spoke light alloy, 3.50” x 17” / Rear Wheel: 10-spoke light alloy, 5.50” x 17” / |
| Front Tyre | Pirelli Diablo Rosso II 120/70 ZR17 |
| Rear Tyre | Pirelli Diablo Rosso II 180/55 -ZR17 |
| Front Wheel Travel | 130 mm / 5.1 in |
| Rear Wheel Travel | 150 mm / 5.91 in |
| Rake: | 24° |
| Trail | 90 mm / 3.54 in |
| FUEL SYSTEM | |
| Fuel Capacity | 16.5 Litres / 4.3 US gal |
| Fuel Reserve | — |
| Fuel Consumption | 53 mpg / 22.5 km/l |
| ADDITIONAL | |
| Top Speed | 120 mph / 193.121 kph |
| Instrumentation | LCD display |
| Standard Equipment | Bosch ABS, LED position light and tail light, USB power socket, |
| Colours | White, Red, Black |
The Monster 797 is even more unmistakeable. The Monster 797 boasts a distinctive look, thanks to standard equipment that includes the front fairing and the passenger seat cover, which both match the tank and front mudguard. This equipment enriches the lines of the Monster and improves riding comfort thanks to the front fairing that optimises the rider’s aerodynamic protection. The Monster 797 is the ideal bike for those who want to enter the world of Ducati for the first time. As sporty and essential as any Monster, it offers everything you need for a fun ride that is also easy and intuitive. In addition, the new graphics give the Monster 797 unique personality and style. The Monster 797 design perfectly integrates wide handlebar, tank, trellis frame, engine and double-sided swinging arm – an agile and dynamic line that communicates sportiness and generates confidence from first glance. The Desmodue twin, with 73 hp and 6,8 kgm of torque, ensures riding enjoyment in maximum safety. The constant, fluid torque curve immediately instils confidence without creating any difficulty. Carefree fun is guaranteed! Thanks to the new graphics the Monster 797 acquires a new, original style.
