Ducati XDiavel Black star 2021 FACTORY SPECIFICATIONS
Ducati XDiavel Black star 2021 FACTORY SPECIFICATIONS
Spec sheet
MODELDucati Xdiavel Black Star
ENGINE TYPEFour stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Year2021
Displacement / Capacity1262 cc / 77 cu in
Bore X Stroke106 x 71.5 mm
Compression Ratio13.0:1
Cooling SystemLiquid Cooled
Max Power Euro5Max Power Euro4118 kW / 160 hp @ 9500 rpm / 112 kW / 152 hp @ 9500 rpm
Max Torque Euro5Max Torque Euro4127 Nm / 93.7 lb-ft @ 5000 rpm / 126 Nm / 92.9 lb-ft @ 5000 rpm
IgnitionElectronic
InductionElectronic fuel injection system, 56mm elliptical throttle bodies full with ride-by-wire system
Start SystemElectric
TRANSMISSION SPECS
Lubrication—
Gear Box6-Speed
ClutchSlipper and self-servo wet multiplate clutch with hydraulic control
Primary / Final DriveFinal Drive : Belt, front sprocket Z28, rear sprocket Z80 / Primary Drive : Straight cut gears, 1.84:1 ratio
Secondary drive—
Gear Ratio1st 37:15 / 2nd 30:17 / 3rd 27:20 / 4th 24:22 / 5th 23:24 / 6th 22:25
CHASSIS SPECS
FrameTubular steel trellis frame
Front Suspension50mm USD adjustable forks with DLC treatment
Rear SuspensionSingle shock absorber, adjustable preload and rebound, remote reservoir, Single sided cast/trellis frame swingarm
BrakesFront Brakes: 2x 320 mm semifloating discs, radial Brembo monobloc 4-piston M4.32 callipers, PR16/19 radial master cylinder / / Rear Brakes : Single 265 mm disc, Brembo 2-piston floating calliper / / ABS: BOSCH cornering ABS as standard equipment
Traction Management—
Exhaust SystemStainless steel exhaust and muffler with dual oval exits, catalytic converter and 2 lambda probes
DIMENSION SPECS
Overall Length—
Seat Height755 mm / 29.7 in
Overall Height—
Overall Width—
Overall WeightDry Weight - 221 kg / 487 lbs / Wet Weight - 247 kg / 545 lbs
Wheelbase1615 mm / 63.6 in
Inner Leg Curve—
WHEEL SPECS
Wheels / RimsFront Wheel : Forged aluminum, 3.50 x 17 / Rear Wheel: Forged aluminum, 8.00 x 17
Front Tyre120/70 ZR17 Pirelli Diablo Rosso III
Rear Tyre240/45 ZR17 Pirelli Diablo Rosso III
Front Wheel Travel120 mm / 4.7 in
Rear Wheel Travel110 mm / 4.3 in
Rake:30°
Trail130 mm / 5.1 in
FUEL SYSTEM
Fuel Capacity18 L / 4.75 US gal
Fuel Reserve—
Fuel Consumption5.5 l/100 km
ADDITIONAL
Top Speed150 mph (Est.) / 241 kmh
Instrumentation3.5" TFT color display and dedicated warning light display
Standard EquipmentDPL (Ducati Power Launch), RbW, Cruise control, Hands-free, Full-LED lighting*, Backlit handlebar switches
EmissionEuro 4 / Euro 5 compliant in all countries that adopt the standard
Photo gallery
xdiavel 2021 black star xdiavel 2021 black star Ducati Xdiavel 2021 Black star Ducati Xdiavel 2021 Black star Ducati Xdiavel 2021 Dark Ducati Xdiavel 2021 Black star Ducati Xdiavel 2021 S Ducati Xdiavel 2021 Black star
Ducati file

Video Courtessy of Ducati

For the entire XDiavel 2021 range, the Ducati Testastretta DVT 1262 twin-cylinder engine becomes Euro 5 compliant in all countries that adopt this standard. To comply with the new European emissions standard, an updated silencer layout has been adopted, with a new design that further enhances the bike's lines and a new engine calibration. As a result, the XDiavel delivers a maximum power output of 160 hp at 9,500 rpm and a maximum torque of 13.0 kgm at 5,000 rpm, with an increase of 8 hp and 0.2 kgm compared to the Euro 4 version. (Only for countries where Euro 5 standard applies.) You can tell it is a Ducati at the first corner: the way it leans, its technical content, its cutting-edge electronic package and high performance guarantee an unforgettable riding experience. The wide handlebar and advanced footpegs of the new XDiavel, on the other hand, offer riding feelings that allow a relaxed and comfortable ride at any speed. The "Dragster" spirit of the XDiavel can be fully expressed thanks to the Ducati Power Launch (DPL). This system can guarantee fast and safe starts thanks to the Bosch IMU which regulates the gas and the intervention of the DTC on the basis of the setting chosen.
