| MODEL | HARLEY-DAVIDSON LIVEWIRE 2020 |
| Year | 2020 |
| Engine Type | Revelation internal permanent magnet synchronous electric motor |
| Displacement / Capacity | — |
| Bore X Stroke | — |
| Compression Ratio | — |
| Cooling System | Liquid cooled (motor water jacket) |
| Max Power | 78 kW / 105 hp |
| Max Torque | 117 Nm / 86 lb-ft |
| Ignition | — |
| Induction | — |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | Single speed |
| Clutch | None |
| Final Drive | Belt, 3/1 ratio (primary spiral bevel gear 55/17) |
| CHASSIS SPECS | |
| Frame | Cast aluminium, cast aluminium swingarm |
| Front Suspension | Showa 43 mm inverted SFF-BP fork, fully adjustable, 115 mm / 4.5 in travel |
| Rear Suspension | Showa BFRC-lite monoshock, fully adjustable, 115 mm / 4.5 in travel |
| Front Brakes | 2 x 300 mm floating discs, 4-piston radial monoblock calipers, ABS |
| Rear Brakes | Single 260 mm floating disc, 2-piston caliper, ABS |
| DIMENSION SPECS | |
| Overall Length | 2135 mm / 84.1 in |
| Overall Width | 830 mm / 32.7 in |
| Overall Height | 1080 mm / 42.5 in |
| Seat Height | 761 mm / 30 in (laden); 780 mm / 30.7 in (unladen) |
| Wheelbase | 1490 mm / 58.7 in |
| Ground Clearance | 130 mm / 5.1 in |
| Dry Weight | — |
| Wet Weight | 249 kg / 549 lbs |
| WHEEL SPECS | |
| Front Tyre | 120/70 ZR17 58W |
| Rear Tyre | 180/55 ZR17 73W |
| FUEL SYSTEM | |
| Fuel Capacity | — |
| Fuel Consumption | — |
| Top Speed | 177 km/h / 110 mph |
The production LiveWire was Harley-Davidson's first electric motorcycle for sale, developed from the 2014 Project LiveWire prototype. A water-jacketed Revelation motor and 15.5 kWh battery give twist-and-go acceleration (0-60 mph in about 3 seconds) with no clutch or gears, and it supports both home AC charging and DC fast charging. Fully adjustable Showa suspension, radial four-piston front brakes and standard ABS and traction control make it a sporty naked roadster rather than a cruiser. For 2021 it carried on as the LiveWire ONE under the new LiveWire brand.
