| MODEL | HARLEY-DAVIDSON ROAD GLIDE FLTR 2007 - 2008 |
| Year | 2007 - 2008 |
| Engine Type | Four-stroke, 45° V-twin, Twin Cam 96, vibration isolation-mounted, pushrod-operated OHV, 2 valves per cylinder, hydraulic self-adjusting lifters |
| Displacement / Capacity | 1584 cc / 96 cu in |
| Bore X Stroke | 95.2 x 111.2 mm / 3.75 x 4.38 in |
| Compression Ratio | 9.2:1 |
| Cooling System | Air cooled |
| Max Power | — |
| Max Torque | 124.7 Nm / 92 lb-ft @ 3000 rpm |
| Ignition | Single-fire, non-wasted, map-controlled spark ignition |
| Induction | Electronic Sequential Port Fuel Injection (ESPFI) |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6-speed |
| Clutch | — |
| Final Drive | Belt |
| CHASSIS SPECS | |
| Frame | Mild steel, square-section backbone with twin downtubes |
| Front Suspension | 41.3 mm telescopic fork, cartridge-style damping |
| Rear Suspension | Short, air-adjustable shocks |
| Front Brakes | 2 x 292 mm discs, 4-piston calipers |
| Rear Brakes | Single 292 mm disc, 4-piston caliper |
| DIMENSION SPECS | |
| Overall Length | 2380 mm / 93.7 in |
| Overall Width | 909 mm / 35.8 in |
| Overall Height | 1397 mm / 55.0 in |
| Seat Height | 683 mm / 26.9 in (laden); 749 mm / 29.5 in (unladen) |
| Wheelbase | 1613 mm / 63.5 in |
| Ground Clearance | 130 mm / 5.1 in |
| Dry Weight | 341 kg / 752 lbs |
| Wet Weight | 357.8 kg / 789 lbs |
| WHEEL SPECS | |
| Front Tyre | MT90B16 72H |
| Rear Tyre | MU85B16 77H |
| FUEL SYSTEM | |
| Fuel Capacity | 18.9 Litres / 5.0 US gal |
| Fuel Consumption | 5.2 L/100 km highway / 7.2 L/100 km city (45 / 32.5 US mpg) |
| Top Speed | — |
The 2007 update gave the Road Glide the larger Twin Cam 96 engine, fuel injection as standard and the six-speed Cruise Drive gearbox, so the carburettor option was dropped and the model became simply FLTR. Chassis, 16-inch wheels and the 5-gallon tank carried over from the previous generation, making this the last Road Glide on the old Touring frame.
