| MODEL | HARLEY-DAVIDSON SOFTAIL BREAKOUT PRO STREET CVO 2016 - 2017 |
| Year | 2016 - 2017 |
| Engine Type | Four-stroke V-twin, Screamin' Eagle Twin Cam 110B |
| Displacement / Capacity | 1801 cc / 110 cu in |
| Bore X Stroke | 101.6 x 111.1 mm |
| Compression Ratio | 9.2:1 |
| Cooling System | Air cooled |
| Max Power | 67.2 kW / 92 hp @ 5000 rpm |
| Max Torque | 151 Nm / 112.1 lb-ft @ 3500 rpm |
| Ignition | — |
| Induction | Electronic Sequential Port Fuel Injection (ESPFI) |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6-speed Cruise Drive |
| Clutch | Hydraulic, wet multi-plate, assist & slip |
| Final Drive | Belt |
| CHASSIS SPECS | |
| Frame | — |
| Front Suspension | 43 mm inverted fork |
| Rear Suspension | — |
| Front Brakes | 2 x 300 mm discs, 4-piston fixed calipers, ABS |
| Rear Brakes | Single 292 mm disc, 2-piston floating caliper, ABS |
| DIMENSION SPECS | |
| Overall Length | 2330 mm / 91.7 in |
| Overall Width | — |
| Overall Height | — |
| Seat Height | 660 mm / 26.0 in |
| Wheelbase | 1680 mm / 66.1 in |
| Ground Clearance | 120 mm / 4.7 in |
| Dry Weight | 318 kg / 701 lbs |
| Wet Weight | 332 kg / 732 lbs |
| WHEEL SPECS | |
| Front Tyre | 130/60B19 61H |
| Rear Tyre | 240/40R18 79V |
| FUEL SYSTEM | |
| Fuel Capacity | 18.9 Litres / 5.0 US gal |
| Fuel Consumption | — |
| Top Speed | — |
A sportier CVO take on the Breakout, aimed at the American performance-bagger and drag-bike crowd. It swapped the standard bike's 21-inch front for a 19-inch Aggressor wheel, fitted 43 mm inverted forks with dual 300 mm front discs, and added a speed screen, chin spoiler, drag bar and dark Smoke Satin Chrome finishes. Power came from the Screamin' Eagle Twin Cam 110B with an assist-and-slip hydraulic clutch, and it was the lowest-priced CVO of its launch year.
