| MODEL | HARLEY-DAVIDSON SOFTAIL CROSS BONES FLSTSB 2010 - 2011 |
| Year | 2010 - 2011 |
| Engine Type | Four stroke, 45° V-twin, Twin Cam 96B (counterbalanced, rigid-mounted), pushrod-operated OHV with hydraulic lifters, 2 valves per cylinder |
| Displacement / Capacity | 1584 cc / 96 cu in |
| Bore X Stroke | 95.2 x 111.2 mm |
| Compression Ratio | 9.2:1 |
| Cooling System | Air cooled |
| Max Power | — |
| Max Torque | 124.7 Nm / 92 lb-ft @ 3000 rpm |
| Ignition | Single-fire, non-wasted, map-controlled spark ignition |
| Induction | Electronic Sequential Port Fuel Injection (ESPFI) |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6 Speed |
| Clutch | Multi-plate, diaphragm spring, wet |
| Final Drive | Belt |
| CHASSIS SPECS | |
| Frame | Mild steel tubular frame, rectangular-section backbone, stamped, cast and forged junctions, MIG welded |
| Front Suspension | Springer leading-link fork, black |
| Rear Suspension | Hidden, horizontally mounted coil-over shocks |
| Front Brakes | Single 292 mm disc, 2-piston caliper |
| Rear Brakes | Single 292 mm disc, 2-piston caliper |
| DIMENSION SPECS | |
| Overall Length | 2299 mm / 90.5 in |
| Overall Width | 968 mm / 38.1 in |
| Overall Height | 1255 mm / 52.6 in |
| Seat Height | 676 mm / 26.6 in (laden); 767 mm / 30.2 in (unladen) |
| Wheelbase | 1638 mm / 64.5 in |
| Ground Clearance | 124 mm / 4.9 in |
| Dry Weight | 317.5 kg / 700 lbs |
| Wet Weight | 334 kg / 737 lbs |
| WHEEL SPECS | |
| Front Tyre | MT90B16 |
| Rear Tyre | 200/55R17 |
| FUEL SYSTEM | |
| Fuel Capacity | 18.9 Litres / 5.0 US gal |
| Fuel Consumption | 35 mpg city / 54 mpg highway (US) |
| Top Speed | — |
The Cross Bones continued for 2010 and 2011, its last two years, with the same recipe: a dark, bobber-styled Softail with a Springer leading-link fork, solo sprung seat and hidden horizontal rear shocks. Power still came from the counterbalanced Twin Cam 96B with a six-speed gearbox and belt drive.
