| MODEL | HARLEY-DAVIDSON SOFTAIL FAT BOB 114 2020 - 2021 |
| Year | 2020 - 2021 |
| Engine Type | Air/oil-cooled 45° V-twin, Milwaukee-Eight 114, pushrod OHV, hydraulic lifters, 4 valves per cylinder |
| Displacement / Capacity | 1868 cc / 113.9 cu in |
| Bore X Stroke | 102 x 114.3 mm / 4.016 x 4.5 in |
| Compression Ratio | 10.5:1 |
| Cooling System | Air cooled |
| Max Power | — |
| Max Torque | 155 Nm / 114 lb-ft @ 3500 rpm |
| Ignition | Single-fire, non-wasted, map-controlled spark ignition |
| Induction | Electronic Sequential Port Fuel Injection (ESPFI) |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Pressurised dry sump with oil cooler |
| Gear Box | 6-speed |
| Clutch | Wet multi-plate |
| Final Drive | Belt |
| CHASSIS SPECS | |
| Frame | Softail steel frame |
| Front Suspension | Showa inverted fork (SDBV cartridge) |
| Rear Suspension | Monoshock, adjustable preload |
| Front Brakes | 2 x discs, 4-piston calipers |
| Rear Brakes | Single disc, 2-piston floating caliper |
| DIMENSION SPECS | |
| Overall Length | 2340 mm / 92.1 in |
| Overall Width | — |
| Overall Height | — |
| Seat Height | 710 mm / 27.9 in (unladen) |
| Wheelbase | 1615 mm / 63.6 in |
| Ground Clearance | 120 mm / 4.7 in |
| Dry Weight | 296 kg / 652.5 lbs |
| Wet Weight | 306 kg / 674.6 lbs |
| WHEEL SPECS | |
| Front Tyre | 150/80-16 71H |
| Rear Tyre | 180/70B16 77H |
| FUEL SYSTEM | |
| Fuel Capacity | 13.6 Litres / 3.6 US gal |
| Fuel Consumption | — |
| Top Speed | — |
From 2020 the Fat Bob 114 carried on as the main Fat Bob model, keeping the aggressive Milwaukee-Eight Softail recipe: big-inch 114 engine, inverted fork, hidden adjustable monoshock, chunky tyres on cast wheels, dual front discs and the upswept 2-1-2 exhaust. It was aimed at riders who wanted a muscle cruiser that could also be ridden hard through corners.
