| MODEL | HARLEY-DAVIDSON SOFTAIL FXDR 114 2019 - 2020 |
| Year | 2019 - 2020 |
| Engine Type | Four stroke, V-twin, Milwaukee-Eight 114, pushrod OHV, hydraulic self-adjusting lifters, 4 valves per cylinder |
| Displacement / Capacity | 1868 cc / 114 cu in |
| Bore X Stroke | 102 x 114.3 mm |
| Compression Ratio | 10.5:1 |
| Cooling System | Air/oil cooled |
| Max Power | 67 kW / 90 hp |
| Max Torque | 161 Nm / 119 lb-ft @ 3500 rpm |
| Ignition | Single-fire, non-wasted, map-controlled spark ignition |
| Induction | Electronic Sequential Port Fuel Injection (ESPFI) |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Pressurised dry sump with oil cooler |
| Gear Box | 6 Speed Cruise Drive |
| Clutch | Wet multi-plate, cable-actuated assist and slip |
| Final Drive | Belt |
| CHASSIS SPECS | |
| Frame | Mild steel Softail frame, cast aluminium swingarm |
| Front Suspension | 43 mm inverted single-cartridge fork, 129.5 mm travel |
| Rear Suspension | Coil-over monoshock, adjustable preload, 86 mm travel |
| Front Brakes | 2x 300 mm floating discs, 4-piston fixed calipers, ABS |
| Rear Brakes | Single 292 mm disc, 2-piston fixed caliper, ABS |
| DIMENSION SPECS | |
| Overall Length | 2425 mm / 95.5 in |
| Overall Width | 925 mm / 36.4 in |
| Overall Height | 1085 mm / 42.7 in |
| Seat Height | 720 mm / 28.3 in (unladen) |
| Wheelbase | 1735 mm / 68.3 in |
| Ground Clearance | 140 mm / 5.5 in |
| Dry Weight | 289 kg / 637 lbs |
| Wet Weight | 303 kg / 668 lbs |
| WHEEL SPECS | |
| Front Tyre | 120/70ZR19 60W |
| Rear Tyre | 240/40R18 79V |
| FUEL SYSTEM | |
| Fuel Capacity | 16.6 Litres / 4.4 US gal |
| Fuel Consumption | 5.1 L/100 km / 46 US mpg |
| Top Speed | — |
The FXDR 114 was Harley's drag-strip-inspired power cruiser, built on the Softail chassis with the Milwaukee-Eight 114 engine. It used an aluminium swingarm, composite tail section, inverted 43 mm fork, 34-degree rake and a fat 240-section rear tyre, with a clipped tail, speed screen and stretched tank giving it a long, low profile. It was dropped after two model years.
