| MODEL | HARLEY-DAVIDSON STREET GLIDE 2016 |
| Year | 2016 |
| Engine Type | Four stroke, 45° V-twin, High Output Twin Cam 103 with integrated oil cooler |
| Displacement / Capacity | 1690 cc / 103 cu in |
| Bore X Stroke | 98.4 x 111.3 mm |
| Compression Ratio | 9.7:1 |
| Cooling System | Air cooled |
| Max Power | 62.6 kW / 85.8 hp @ 5000 rpm |
| Max Torque | 142 Nm / 104.7 lb-ft @ 3250 rpm |
| Ignition | Single-fire, non-wasted, map-controlled spark ignition |
| Induction | Electronic Sequential Port Fuel Injection (ESPFI) |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Dry sump |
| Gear Box | 6 Speed |
| Clutch | Multi-plate wet, diaphragm spring |
| Final Drive | Belt |
| CHASSIS SPECS | |
| Frame | Mild steel, square-section backbone with twin downtubes |
| Front Suspension | 41.3 mm telescopic fork, cartridge-style damping, 117 mm / 4.6 in travel |
| Rear Suspension | Short, air-adjustable shocks, 51 mm / 2.0 in travel |
| Front Brakes | 2 x 292 mm discs, 4-piston calipers |
| Rear Brakes | Single 292 mm disc, 4-piston caliper |
| DIMENSION SPECS | |
| Overall Length | 2450 mm / 96.5 in |
| Overall Width | — |
| Overall Height | — |
| Seat Height | 663 mm / 26.1 in (laden); 688 mm / 27.1 in (unladen) |
| Wheelbase | 1613 mm / 63.5 in |
| Ground Clearance | 135 mm / 5.3 in |
| Dry Weight | 355 kg / 775 lbs |
| Wet Weight | 372 kg / 810 lbs |
| WHEEL SPECS | |
| Front Tyre | 130/70B18 63H |
| Rear Tyre | 180/65B16 81H |
| FUEL SYSTEM | |
| Fuel Capacity | 22.7 Litres / 6.0 US gal |
| Fuel Consumption | 5.6 L/100 km / 42 mpg (US) |
| Top Speed | — |
The 2016 Street Glide was the last Twin Cam version, using the High Output Twin Cam 103 in the Rushmore chassis with linked ABS brakes, LED lighting and stiffer forks. Cruise control became standard, alongside the Boom! Box 4.3 radio with USB input, one-touch saddlebags and the vented batwing fairing.
