| MODEL | HONDA CB 300F 2015 - 2016 |
| Year | 2015 - 2016 |
| Engine Type | Four stroke, single cylinder, DOHC, 4 valves per cylinder |
| Displacement / Capacity | 286 cc / 17.45 cu in |
| Bore X Stroke | 76 x 63 mm |
| Compression Ratio | 10.7:1 |
| Cooling System | Liquid cooled |
| Max Power | 21.5 kW / 29.5 hp @ 8500 rpm |
| Max Torque | 27 Nm / 19.9 lb-ft @ 7250 rpm |
| Ignition | Computer-controlled digital transistorised with electronic advance |
| Induction | PGM-FI electronic fuel injection, 38 mm throttle body |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6 Speed |
| Clutch | Wet multiplate |
| Final Drive | #520 O-ring sealed chain |
| CHASSIS SPECS | |
| Frame | Diamond, steel twin-spar |
| Front Suspension | 37 mm telescopic fork, 120 mm / 4.7 in travel |
| Rear Suspension | Pro-Link monoshock, 5-position preload, 103 mm / 4.1 in travel |
| Front Brakes | Single 296 mm disc, 2-piston caliper (ABS optional) |
| Rear Brakes | Single 220 mm disc, 1-piston caliper |
| DIMENSION SPECS | |
| Overall Length | 2035 mm / 80.1 in |
| Overall Width | 720 mm / 28.3 in |
| Overall Height | 1120 mm / 44.1 in |
| Seat Height | 780 mm / 30.7 in |
| Wheelbase | 1380 mm / 54.3 in |
| Ground Clearance | 150 mm / 5.9 in |
| Dry Weight | — |
| Wet Weight | 158 kg / 348 lbs |
| WHEEL SPECS | |
| Front Tyre | 110/70-17 |
| Rear Tyre | 140/70-17 |
| FUEL SYSTEM | |
| Fuel Capacity | 13 Litres / 3.4 US gal |
| Fuel Consumption | 3.3 L/100 km / 71 US mpg |
| Top Speed | — |
The CB300F was the naked version of the CBR300R, launched for 2015 with the same 286 cc liquid-cooled, fuel-injected single and a counterbalancer. A low seat, light weight and broad low-rev pull made it aimed at newer riders and commuters, with ABS available as an option. It was assembled in Thailand.
