| MODEL | HONDA CB 750 HORNET 2023 |
| Year | 2023 |
| Engine Type | Four stroke, parallel twin, 270° crank, Unicam OHC, 4 valves per cylinder |
| Displacement / Capacity | 755 cc / 46 cu in |
| Bore X Stroke | 87 x 63.5 mm |
| Compression Ratio | 11.0:1 |
| Cooling System | Liquid cooled |
| Max Power | 67.5 kW / 90 hp @ 9500 rpm |
| Max Torque | 75 Nm / 55.3 lb-ft @ 7250 rpm |
| Ignition | — |
| Induction | PGM-FI electronic fuel injection |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 6 Speed |
| Clutch | Wet multi-plate, assist/slipper |
| Final Drive | Chain |
| CHASSIS SPECS | |
| Frame | Steel diamond |
| Front Suspension | 41 mm Showa SFF-BP USD fork, 130 mm / 5.1 in travel |
| Rear Suspension | Monoshock, Pro-Link swingarm, 150 mm / 5.9 in travel |
| Front Brakes | 2 x 296 mm floating discs, 4 piston Nissin radial calipers, ABS |
| Rear Brakes | Single 240 mm disc, 1 piston caliper, ABS |
| DIMENSION SPECS | |
| Overall Length | 2090 mm / 82.3 in |
| Overall Width | 780 mm / 30.7 in |
| Overall Height | 1085 mm / 42.7 in |
| Seat Height | 795 mm / 31.3 in |
| Wheelbase | 1420 mm / 55.9 in |
| Ground Clearance | 140 mm / 5.5 in |
| Dry Weight | — |
| Wet Weight | 190 kg / 419 lbs |
| WHEEL SPECS | |
| Front Tyre | 120/70 ZR17 |
| Rear Tyre | 160/60 ZR17 |
| FUEL SYSTEM | |
| Fuel Capacity | 15.2 Litres / 4.0 US gal |
| Fuel Consumption | 4.35 L/100 km / 54 mpg (US) |
| Top Speed | — |
The CB750 Hornet revived the Hornet name for Honda's middleweight naked bike, replacing the old four-cylinder CB600F concept with an all-new 755 cc parallel twin using a 270° crank and Unicam head. A light steel diamond frame, Showa SFF-BP fork and radial Nissin brakes keep it agile, while ride-by-wire brings riding modes, traction and wheelie control and a 5-inch TFT dash. It is aimed at riders wanting a lively, affordable everyday streetbike.
