| MODEL | HONDA CLR 125 CITYFLY 1998 - 2003 |
| Year | 1998 - 2003 |
| Engine Type | Four stroke, single cylinder, SOHC |
| Displacement / Capacity | 124 cc / 7.6 cu in |
| Bore X Stroke | 56.5 x 49.5 mm / 2.22 x 1.95 in |
| Compression Ratio | 9.2:1 |
| Cooling System | Air cooled |
| Max Power | 8.4 kW / 11.4 PS @ 8250 rpm |
| Max Torque | 10.4 Nm @ 6750 rpm |
| Ignition | — |
| Induction | — |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 5 Speed |
| Clutch | — |
| Final Drive | Chain |
| CHASSIS SPECS | |
| Frame | Diamond |
| Front Suspension | Telescopic fork |
| Rear Suspension | Swing arm |
| Front Brakes | Single 240 mm disc |
| Rear Brakes | 110 mm drum |
| DIMENSION SPECS | |
| Overall Length | 2070 mm / 81 in |
| Overall Width | 780 mm / 31 in |
| Overall Height | 1135 mm / 44.7 in |
| Seat Height | 815 mm / 32.1 in |
| Wheelbase | 1380 mm / 54 in |
| Ground Clearance | — |
| Dry Weight | 118 kg / 260 lbs |
| Wet Weight | 128 kg / 282 lbs |
| WHEEL SPECS | |
| Front Tyre | 90/90-19 |
| Rear Tyre | 110/90-17 |
| FUEL SYSTEM | |
| Fuel Capacity | — |
| Fuel Consumption | — |
| Top Speed | 100 km/h / 62 mph |
Photo: Nitot, CC BY-SA 4.0, via Wikimedia Commons
Photo: David96cz, CC BY-SA 4.0, via Wikimedia Commons
The CLR 125 CityFly was a European-market light dual-purpose 125 made by Montesa-Honda in Spain, using a single-cylinder engine derived from the XLR125 trail bike. Its 19-inch front wheel, upright bars and simple chassis suggested off-road ability, but most owners used it as a tough, easy commuter. A restricted 80 km/h version was also offered for younger riders.
