| MODEL | HONDA CRF 300L 2023 |
| Year | 2023 |
| Engine Type | Four stroke single cylinder, DOHC, 4 valves |
| Displacement / Capacity | 286 cc / 17.4 cu in |
| Bore X Stroke | 76 x 63 mm |
| Compression Ratio | 10.7:1 |
| Cooling System | Liquid cooled |
| Max Power | 20.1 kW / 27 hp @ 8500 rpm |
| Max Torque | 26.6 Nm / 19.6 lb-ft @ 6500 rpm |
| Ignition | Full transistor digital |
| Induction | PGM-FI electronic fuel injection |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Wet sump |
| Gear Box | 6 Speed |
| Clutch | Wet multiplate, assist/slipper clutch |
| Final Drive | #520 chain |
| CHASSIS SPECS | |
| Frame | Steel semi-double cradle |
| Front Suspension | 43 mm telescopic USD fork |
| Rear Suspension | Pro-Link single shock with spring |
| Front Brakes | Single 256 mm disc, 2-piston caliper, 2-channel ABS |
| Rear Brakes | Single 220 mm disc, 1-piston caliper, ABS |
| DIMENSION SPECS | |
| Overall Length | 2230 mm / 87.7 in |
| Overall Width | 820 mm / 32.2 in |
| Overall Height | 1200 mm / 47.2 in |
| Seat Height | 880 mm / 34.6 in |
| Wheelbase | 1455 mm / 57.2 in |
| Ground Clearance | 285 mm / 11.2 in |
| Dry Weight | — |
| Wet Weight | 142 kg / 313 lbs |
| WHEEL SPECS | |
| Front Tyre | 80/100-21 M/C 51P |
| Rear Tyre | 120/80-18 M/C 62P |
| FUEL SYSTEM | |
| Fuel Capacity | 7.8 Litres / 2.0 US gal |
| Fuel Consumption | — |
| Top Speed | — |
The 2023 CRF300L was mechanically unchanged from the 2021 relaunch, keeping the 286 cc Euro 5 single, slipper clutch, light steel chassis and long-travel suspension. Honda added a Swift Gray colour option and made knuckle guards standard on both colour schemes.
