| MODEL | HONDA XR 150L 2014 - 2016 |
| Year | 2014 - 2016 |
| Engine Type | Four stroke, single cylinder, OHC |
| Displacement / Capacity | 149 cc / 9.0 cu in |
| Bore X Stroke | 57.3 x 57.8 mm |
| Compression Ratio | 9.5:1 |
| Cooling System | Air cooled |
| Max Power | 9.05 kW / 12.1 hp @ 7750 rpm |
| Max Torque | 12.5 Nm / 9.2 lb-ft @ 6000 rpm |
| Ignition | CDI |
| Induction | — |
| Start System | Electric & kick |
| TRANSMISSION SPECS | |
| Lubrication | — |
| Gear Box | 5 Speed |
| Clutch | — |
| Final Drive | Chain |
| CHASSIS SPECS | |
| Frame | — |
| Front Suspension | 31 mm telescopic fork |
| Rear Suspension | Monoshock, 150 mm travel |
| Front Brakes | Single 240 mm disc, 2-piston caliper |
| Rear Brakes | 110 mm drum |
| DIMENSION SPECS | |
| Overall Length | 2090 mm / 82.2 in |
| Overall Width | 810 mm / 31.8 in |
| Overall Height | 1125 mm / 44.2 in |
| Seat Height | — |
| Wheelbase | 1360 mm / 53.5 in |
| Ground Clearance | 245 mm / 9.6 in |
| Dry Weight | — |
| Wet Weight | 130 kg / 286.6 lbs |
| WHEEL SPECS | |
| Front Tyre | 90/90-19 |
| Rear Tyre | 110/90-17 |
| FUEL SYSTEM | |
| Fuel Capacity | 12 Litres / 3.1 US gal |
| Fuel Consumption | — |
| Top Speed | — |
Introduced in 2014 as the successor to the XR 125L, the XR 150L uses a larger 149 cc air-cooled single with a balancer shaft, offset crankshaft and roller rockers for smoother running and durability. Low gearing, electric start, a luggage rack and a 12-litre tank make it a road-legal workhorse for farms and rural roads as much as a commuter.
