| MODEL | HONDA XR 200R 2002 |
| Year | 2002 |
| Engine Type | Four-stroke, single cylinder, SOHC, 2 valves, chain-driven camshaft |
| Displacement / Capacity | 195 cc / 11.8 cu in |
| Bore X Stroke | 67 x 56.5 mm |
| Compression Ratio | 10.0:1 |
| Cooling System | Air cooled |
| Max Power | 17.1 kW / 23 hp @ 9000 rpm |
| Max Torque | 19.5 Nm / 14.4 lb-ft @ 7500 rpm |
| Ignition | Solid state CDI |
| Induction | 2x 20 mm piston valve Keihin carburettor |
| Start System | Kick |
| TRANSMISSION SPECS | |
| Lubrication | Forced pressure, wet sump |
| Gear Box | Close-ratio 6-speed |
| Clutch | Wet multiplate |
| Final Drive | Chain |
| CHASSIS SPECS | |
| Frame | Semi double cradle |
| Front Suspension | 36 mm air-adjustable fork with dual Syntallic bushings, 208 mm / 8.1 in travel |
| Rear Suspension | Pro-Link, single adjustable Showa shock, 211 mm / 8.3 in travel |
| Front Brakes | Drum, swept area 86.3 cm2 / 13.3 sq in |
| Rear Brakes | Drum, swept area 86.3 cm2 / 13.3 sq in |
| DIMENSION SPECS | |
| Overall Length | 2035 mm / 80.1 in |
| Overall Width | 865 mm / 34.1 in |
| Overall Height | 1180 mm / 46.5 in |
| Seat Height | 850 mm / 33.5 in |
| Wheelbase | 1360 mm / 53.5 in |
| Ground Clearance | 315 mm / 12.4 in |
| Dry Weight | 102 kg / 224.8 lbs |
| Wet Weight | 109 kg / 240 lbs |
| WHEEL SPECS | |
| Front Tyre | 80/100-21 |
| Rear Tyre | 100/100-17 |
| FUEL SYSTEM | |
| Fuel Capacity | 9.0 Litres / 2.4 US gal |
| Fuel Consumption | — |
| Top Speed | — |
2002 was the final US year for the XR200R before the CRF230F replaced it. The motorcyclespecs table shows this last version with shorter suspension travel, a slightly shorter wheelbase and narrower 80/100-21 and 100/100-17 tyres than earlier bikes, plus a close-ratio six-speed gearbox. It closed out a two-valve air-cooled line that had run since 1986.
