| MODEL | KTM 1190 ADVENTURE 2015 |
| Year | 2015 |
| Engine Type | Four stroke, 75 degree V-twin, DOHC, 4 valves per cylinder |
| Displacement / Capacity | 1195 cc / 72.9 cu in |
| Bore X Stroke | 105 x 69 mm |
| Compression Ratio | 12.5:1 |
| Cooling System | Liquid cooling |
| Max Power | 147.5 hp / 107.7 kW @ 9500 rpm |
| Max Torque | 92.2 lb-ft / 124.8 Nm @ 7500 rpm |
| Ignition | Contactless, controlled, fully electronic ignition with digital timing adjustment |
| Induction | EFI, ride by wire |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Forced oil lubrication with 3 rotor pumps |
| Gear Box | 6 speed (primary 40:76, secondary 17:42) |
| Clutch | Wet multi-disc clutch, hydraulically operated |
| Final Drive | Chain 5/8 x 5/16 in X-Ring |
| CHASSIS SPECS | |
| Frame | Tubular space frame, chrome-molybdenum steel, powder coated |
| Front Suspension | 48mm WP USD forks, 190 mm / 7.5 in wheel travel |
| Rear Suspension | WP-PDS rear shock, hydraulic spring preload, 210 mm / 8.2 in wheel travel |
| Front Brakes | 2 x 320 mm discs, 4-piston calipers |
| Rear Brakes | Single 267 mm disc, 2-piston caliper |
| DIMENSION SPECS | |
| Overall Length | — |
| Overall Width | — |
| Overall Height | — |
| Seat Height | 861 mm - 876 mm / 33.9 in - 34.5 in |
| Wheelbase | 1600 mm / 63.0 in |
| Ground Clearance | 220 mm / 8.7 in |
| Dry Weight | 217 kg / 478.4 lb |
| Wet Weight | — |
| WHEEL SPECS | |
| Front Tyre | 120/70 ZR19 |
| Rear Tyre | 170/60 ZR17 |
| FUEL SYSTEM | |
| Fuel Capacity | 23 Litres / 6.08 US gal |
| Fuel Consumption | — |
| Top Speed | — |
The 2015 KTM 1190 Adventure is the road-biased travel enduro of the 1190 range, pairing a lightweight 1195 cc V-twin with electronic rider aids. It has Bosch MSC, four traction control modes (Sport, Street, Rain and Offroad) and cornering ABS, with the Rain and Offroad modes limiting power. Standard kit includes an adjustable windscreen, adjustable seat and ergonomics, a multi-function display and an immobiliser, and service intervals are 15,000 km.
